Alpha Wire 1131C SL001 Communication Control Cable 1 Pair Stranded 18 AWG 300 V PVC

Alpha Wire 1131C SL001 communication and control industrial cable features 1 pair of 18 AWG (AMERICAN WIRE GAUGE) stranded, tinned copper conductors with PVC-polyvinyl chloride insulation and a PVC-polyvinyl chloride jacket. It is rated 300 V and has a SLATE jacket. The pair is cabled with 5.3 twists/foot (min) and includes a clear Mylar tape core wrap with 25% overlap, min.

Key Features

• 1 pair construction with stranded, tinned copper conductors.
• 18 AWG (AMERICAN WIRE GAUGE) conductor size.
• PVC-polyvinyl chloride insulation and PVC-polyvinyl chloride jacket.
• SLATE jacket color.
• 300 V voltage rating.
• 5.3 twists/foot (min) cabling twist.
• Clear Mylar tape core wrap with 25% overlap, min.
• NEC rating: UL Listed Art 800.
• Fire rating: general purpose.
• Screen/shield: no.

Applications

• Use in communication and control industrial cable installations where reliable signal transmission is needed in demanding environments.
• Support paired-conductor signal wiring where a consistent twist is specified for the cabled pair.

Technical Specs

Component	1 X 1 PAIR
Conductor construction	18 (16/30) AWG Tinned Copper
Conductor diameter (In)	0.047
Insulation wall	0.016" Wall, Nom. PVC
Insulation diameter (In)	0.079
Cabling	2 Cond cabled
Orientation	Components to be arranged from Inside layer to Outside layer
Jacket wall	0.032" Wall, Nom.,PVC
Overall diameter (In)	0.225 (0.235 Max.)
Color code	Alpha Wire Color Code A
Pair 1 color	Black-Red

Cable Print

ALPHA WIRE-* P/N 1131C 1PR 18 AWG 75C (UL) TYPE CM OR AWM 2464 OR C(UL) 75C TYPE CMG FT4 CE ROHS * = Factory Code [Note: Product may have c(UL) or CSA markings depending upon plant of manufacture.]
