Alpha Wire 1218C SL001, Communication Control Industrial Cable 8C 24 AWG Foil 300 V PVC

Part Number: 1218C SL001

Alpha Wire 1218C SL001 is a communication and control industrial cable built for reliable signal transmission in demanding environments. It features 8 conductors of 24 AWG (American Wire Gauge) tinned copper in a stranded construction, with an overall foil shield and drain to help reduce EMI/RFI. The cable uses PVC-polyvinyl chloride insulation and a PVC-polyvinyl chloride jacket, rated 300 V with a general purpose fire rating. A slate outer jacket and defined Alpha Wire Color Code D conductor identification support clean, consistent installations.

Conductor & Electrical:

• Number of conductors: 8 conductors
• Conductor size: 24 AWG (American Wire Gauge)
• Conductor material: Tinned copper
• Conductor type: Stranded conductor
• Voltage rating: 300 V

Insulation & Jacket:

• Insulation material: PVC-polyvinyl chloride
• Insulation: 0.010" wall, nom. PVC, semi rigid
• Jacket material: PVC-polyvinyl chloride
• Jacket: 0.032" wall, nom., PVC
• Jacket color(s): Slate
• Overall diameter: 0.214 (0.227 Max.)

Shielding:

• Shield: Yes
• Screen/shield type: Foil shielded - Alum/Mylar
• Shield construction: Overall shield & drain
• Shield: Alum/Mylar tape, 25% overlap, min.
• Foil direction: Foil facing out
• Drain wire: 24 (7/32) AWG tinned copper

Construction Details:

• Component 1: 8 X 1 COND
• Conductor diameter ("in"): 0.024
• Insulation diameter ("in"): 0.044
• Cable assembly: 8 components cabled
• Twists: 6.0 Twists/foot (min)
• Orientation: Components to be arranged from INSIDE LAYER to OUTSIDE LAYER

Conductor Identification (Alpha Wire Color Code D):

• 1: Black
• 2: Red
• 3: White
• 4: Green
• 5: Orange
• 6: Blue
• 7: Brown
• 8: Yellow

Ratings & Compliance:

• Fire rating: General purpose
• NEC rating: UL listed ART 800

Cable Print (as marked):

• ALPHA WIRE-* P/N 1218C 8C 24 AWG
• SHIELDED 75C (UL) TYPE CM OR AWM 2576 --- LLXXXXXX
• CSA TYPE CMG FT4 CE ROHS
• * = Factory Code
• Note: Product may have c(UL) or CSA markings depending upon plant of manufacture.
