Alpha Wire 1232 SV001, FIT Wire Management Flat Braid 46 Current Rating
SKU:1232 SV001
● In stock
ft
Minimum order: 100 ft · Increments of 100 ft
Description
Part Number: 1232 SV001
Alpha Wire 1232 SV001 is a FIT wire management flat braid designed for flexible grounding, bonding, and shielding applications where a low-profile conductor is needed. It features a tinned copper conductor built to ASTM B-33 and CID-A-A-59551, latest revision, helping support corrosion resistance and reliable conductivity. The braid has nominal dimensions of .375 x .030 Inches with an approximate equivalent size of 12 and an approximate ampacity of 46 Amps. It is RoHS compliant and engineered for dependable performance in electrical and electronic assemblies.
General:
- Brand: Alpha Wire
- Part Number: 1232 SV001
- Product Type: Braid
- RoHS Compliant: Yes
Conductor:
- Conductor Material: Tinned copper, per ASTM B-33 and CID-A-A-59551, latest revision
- Conductor Size: 12 AWG (American Wire Gauge)
- Stranding: Solid
Braid Data:
- Nominal Dimensions: .375 x .030 Inches
- AWG of Ends: 36
- Number of Carriers: 48
- Total Number of Ends: 288
- Nominal Percent Coverage: N/A
- Approx. Equiv. AWG: 12
- Approx. Ampacity: 46 Amps
Electrical:
- DC Resistance, Nominal: 2.04 Ohms/1000 ft.
Compliance / Reference:
- Federal Spec Number: N/A
Specifications
| Attribute | Value |
|---|---|
| Priced Per | FT |
Images are for reference only. Specifications may change without notice — verify suitability for your application before purchase. The manufacturer's documentation controls.
