Alpha Wire 1233 SV005, FIT Wire Management Flat Braid 53 Current Rating
Description
Part Number: 1233 SV005
Alpha Wire 1233 SV005 is a FIT wire management flat braid designed for flexible grounding and bonding applications where a low-profile conductor is needed. It features a solid tinned copper conductor built to ASTM B-33 and CID-A-A-59551, latest revision, and is RoHS compliant. The braid has nominal dimensions of .625 x .030 Inches and an approximate ampacity of 53 Amps for robust current handling. This product is not shielded and is specified under Federal Spec Number AA59569F36T0375.
General:
- Brand: Alpha Wire
- Part Number: 1233 SV005
- Product Type: Braid
- RoHS Compliant: Yes
- Shielding: Not shielded
Conductor:
- Conductor Material: Tinned copper
- Material Standard: Tinned Copper, per ASTM B-33 and CID-A-A-59551, latest revision
- Stranding: Solid
Braid Data:
- Nominal Dimensions: .625 x .030 Inches
- AWG of Ends: 36
- Number of Carriers: 48
- Total Number of Ends: 384
- Approx. Equiv. AWG: 10
- Approx. Ampacity: 53 Amps
- Nominal Percent Coverage: N/A
Electrical:
- DC Resistance, Nominal: 1.53 Ohms/1000 ft.
Compliance & Specifications:
- Federal Spec Number: AA59569F36T0375
Specifications
| Attribute | Value |
|---|---|
| Priced Per | FT |
