Alpha Wire 1293C SL001, Communication Control Industrial Cable 3C 22 AWG Foil 300 V PVC

Part Number: 1293C SL001

Alpha Wire 1293C SL001 is a communication and control industrial cable built with 3 conductors of 22 AWG tinned copper for reliable signal transmission in demanding environments. It features an overall foil shield (Alum/Mylar) with an integrated drain wire to help reduce EMI/RFI, along with PVC insulation and a PVC jacket for durable, general-purpose use. The cable is cabled with 8.0 Twists/foot (min) and finished in a Slate, Blue jacket with manufacturer print markings for easy identification. It is rated 300 V and includes UL Listed Art 800 and additional CM/AWM 2576 and CSA CMG FT4 markings as printed on the jacket.

Conductors:

• Number of Conductors: 3 Conductors
• Conductor Size: 22 AWG (American Wire Gauge)
• Conductor Construction: 22 (7/30) AWG Tinned Copper
• Conductor Type: Stranded Conductor
• Conductor Material: Tinned Copper
• Conductor Diameter ("in"): 0.030

Insulation:

• Insulation Material: PVC-Polyvinyl Chloride
• Insulation Description: 0.010" Wall, Nom. PVC, Semi-Rigid
• Insulated Conductor Diameter ("in"): 0.050
• Color Code: Alpha Wire Color Code D
• Conductor 1 Color: Black
• Conductor 2 Color: Red
• Conductor 3 Color: White

Cabling:

• Assembly: 3 Components Cabled
• Twists: 8.0 Twists/foot (min)
• Orientation: Components to be arranged from Inside Layer to Outside Layer

Shielding:

• Shield: Yes
• Screen/Shield Type: Foil Shielded - Alum/Mylar
• Shield Construction: Overall Shield & Drain
• Shield Material: Alum/Mylar Tape, 25% Overlap, min.
• Foil Direction: Foil Facing Out
• Drain Wire: 22 (7/30) AWG Tinned Copper

Jacket:

• Jacket Material: PVC-Polyvinyl Chloride
• Jacket Description: 0.032" Wall, Nom. PVC
• Overall Diameter ("in"): 0.176 (0.186 max)
• Jacket Color(s): Slate, Blue
• Jacket Print: ALPHA WIRE-* P/N 1293C 3C 22 AWG
  SHIELDED 75C (UL) TYPE CM OR AWM 2576 --- LLXXXXXX
  CSA TYPE CMG FT4 CE ROHS
  * = Factory Code
  Note: Product may have c(UL) or CSA markings depending upon plant of manufacture.

Ratings & Compliance:

• Voltage Rating: 300 V
• Fire Rating: General Purpose
• NEC Rating: UL Listed Art 800
