Alpha Wire 1299/10C SL001, Communication Control Industrial Cable 10C 22 AWG Foil 300 V PVC
SKU:1299/10C SL001
● In stock
ft
Minimum order: 100 ft
Description
Part Number: 1299/10C SL001
Alpha Wire 1299/10C SL001 is a communication and control industrial cable built for reliable signal transmission in demanding environments. It features 10 conductors of 22 AWG stranded tinned copper for flexibility and consistent electrical performance. For improved noise protection, it includes a foil shielded - alum/mylar design with an overall shield & drain. The cable uses PVC-polyvinyl chloride for both insulation and jacket and is rated 300 V for industrial control and communication applications.
Conductors:
- Number of Conductors: 10 CONDUCTORS
- Conductor Size: 22 AWG (AMERICAN WIRE GAUGE)
- Conductor Material: TINNED COPPER
- Conductor Type: STRANDED CONDUCTOR
Shielding:
- Screen/Shield: YES
- Screen/Shield Type: FOIL SHIELDED - ALUM/MYLAR
- Shield Construction: OVERALL SHIELD & DRAIN
Materials:
- Insulation Material: PVC-POLYVINYL CHLORIDE
- Jacket Material: PVC-POLYVINYL CHLORIDE
Ratings & Compliance:
- Voltage Rating: 300 V
- Fire Rating: General Purpose
- NEC Rating: UL LISTED ART 800
Specifications
| Attribute | Value |
|---|---|
| Priced Per | FT |
Images are for reference only. Specifications may change without notice — verify suitability for your application before purchase. The manufacturer's documentation controls.
