Alpha Wire 15-1030 SL199, Composite Cable 8C 18 AWG Shielded 600V TPE Jacket

Part Number: 15-1030 SL199

Alpha Wire 15-1030 SL199 is a composite cable built for reliable signal and power runs where flexibility and durability matter. It features 8 conductors of 18 AWG (American Wire Gauge) stranded, tinned copper for dependable conductivity and easier termination. An overall braid shield helps reduce EMI/RFI in electrically noisy environments, while the TPE-thermoplastic elastomer jacket supports rugged handling. Rated 600V with a general purpose fire rating, it’s well-suited for industrial equipment, control, and instrumentation applications.

Conductors:

• Number of Conductors: 8 conductors
• Conductor Size: 18 AWG (American Wire Gauge)
• Conductor Material: Tinned copper
• Conductor Type: Stranded conductor

Insulation & Jacket:

• Insulation Material: MPPE-modified polyphenylene
• Jacket Material: TPE-thermoplastic elastomer

Shielding:

• Shield: Yes
• Screen/Shield Type: Braid shielded
• Shield Construction: Overall braid shield

Ratings:

• Voltage Rating: 600V
• Fire Rating: General purpose
