Alpha Wire 15-1031 SL199, Composite Cable 19C 18 AWG Shielded 600V TPE Jacket

Part Number: 15-1031 SL199

Alpha Wire 15-1031 SL199 is a composite cable built for reliable multi-conductor signal and control applications where durability and noise reduction matter. It features 19 Conductors of 18 AWG (American Wire Gauge) stranded, tinned copper Conductors for flexibility and dependable conductivity. For EMI protection, the cable includes an Overall Braid Shield (Braid Shielded) and is rated 600V. A TPE-THERMOPLASTIC ELASTOMER jacket and MPPE-MODIFIED POLYPHENYLENE insulation help support performance in demanding general-purpose environments.

Conductors:

• Number of Conductors: 19 Conductors
• Conductor Size: 18 AWG (American Wire Gauge)
• Conductor Type: Stranded Conductor
• Conductor Material: TINNED COPPER

Shielding:

• Shield: Yes
• Screen/Shield Type: Braid Shielded
• Shield Construction: Overall Braid Shield

Materials:

• Insulation Material: MPPE-Modified Polyphenylene
• Jacket Material: TPE-Thermoplastic Elastomer

Ratings:

• Voltage Rating: 600V
• Fire Rating: General Purpose
