Alpha Wire 1555 RD001, Premium Hook Up Wire 18 AWG 1000 V PVC Insulation

Part Number: 1555 RD001

Alpha Wire 1555 RD001 is a premium hook up wire built for dependable internal wiring where flexibility and durability matter. It features an 18 AWG Tinned Copper Conductor with 16 strands in each Conductor, paired with Nom. PVC Insulation for reliable handling and termination. Designed to meet MIL-W-76 requirements, it is rated for 80 Degrees Centigrade (176 F) and is RoHS compliant. This wire is not shielded and is well-suited for general-purpose electrical and electronic applications requiring 1000 V PVC Insulation (as provided in the title).

Conductor

• Conductor Material: Tinned Copper
• Conductor Size: 18 AWG (American Wire Gauge)
• Conductor Stranding: 16 Strands In Each Conductor
• Construction (Conductor): 18 (16/30) AWG Tinned Copper
• Conductor Diameter (In): 0.047

Insulation

• Insulation Material: PVC-Polyvinyl Chloride
• Insulation Color: Red
• Insulation Wall: 0.016" Wall, Nom. PVC
• Insulation Diameter (In): 0.079+/- 0.002

Electrical, Temperature & Compliance

• Temperature Rating: 80 Degrees Centigrade (176 F)
• RoHS Compliant: Yes
• Shielded: Not Shielded

Standards & Type

• Mil Spec: MIL-W-76
• Product Type: MW-76

Construction Overview

• Component: 1 X 1 Hookup

Available Color(s) (Manufacturer Listing)

• White, Black, Red, Green, Yellow, Blue, Brown
• Orange, Slate, Violet, White/Black, White/Red
• White/Green, White/Yellow, White/Blue
• White/Brown, White/Orange, White/Slate
• White/Violet, Red/Yellow
