Alpha Wire 1857/19 BK001, Hook Up Wire 18AWG Black

Part Number: 1857/19 BK001

Alpha Wire 1857/19 BK001 is a flexible hook up wire built for dependable internal wiring in control panels, appliances, and general electronic equipment. It features an 18 AWG Tinned Copper Conductor with 19 strands for a balance of conductivity and ease of routing. The PVC-polyvinyl chloride Insulation is rated to 105 Degrees Centigrade (221 F) and meets MIL-W-16878/1 (Type B) requirements. This wire is RoHS compliant and Not Shielded for straightforward point-to-point connections.

Wire Type & Compliance:

• Product type: M16878
• Mil spec: MIL-W-16878/1 (Type B)
• RoHS compliant: Yes
• Shielding: Not Shielded

Conductor:

• Conductor Material: Tinned Copper
• Conductor Size: 18 AWG (American Wire Gauge)
• Conductor Stranding: 19 strands in each Conductor
• Construction (Conductor): 18 (19/30) AWG Tinned Copper
• Conductor Diameter (In): 0.050

Insulation:

• Insulation Material: PVC-polyvinyl chloride
• Insulation Color: Black
• Insulation wall: 0.010" Wall, Nom. PVC
• Insulation Diameter (In): 0.070+/- 0.002

Temperature Rating:

• 105 Degrees Centigrade (221 F)

Construction Overview:

• Component: 1 X 1 Hookup
• Available color(s): WHITE, BLACK, RED, GREEN, YELLOW, BLUE, BROWN
  ORANGE, SLATE, VIOLET, WHITE/BLACK, WHITE/RED
  WHITE/GREEN, WHITE/YELLOW, WHITE/BLUE
  WHITE/BROWN, WHITE/ORANGE, WHITE/SLATE
  WHITE/VIOLET
