Alpha Wire 5390/15C SL001, Xtra Guard 1 Xtra Guard Performance Cable 15C 18 AWG Foil 300 V PVC

Part Number: 5390/15C SL001

Alpha Wire 5390/15C SL001 Xtra Guard 1 Xtra Guard Performance Cable is a flexible, shielded multi-Conductor cable built for reliable signal integrity in industrial and control applications. It features 15 Conductors of 18 AWG (American Wire Gauge) Stranded, Tinned Copper Conductors with Pvc-Polyvinyl Chloride Insulation and a Pvc-Polyvinyl Chloride Jacket. For noise reduction, it includes a FOIL SHIELDED - ALUM/MYLAR overall Shield with drain. Rated 300 V and UL Listed Art 800, it’s a Solid choice where durability and shielding performance are required.

Conductors:

• Number Of Conductors: 15 Conductors
• Conductor Size: 18 AWG (American Wire Gauge)
• Conductor Material: Tinned Copper
• Conductor Type: Stranded Conductor

Insulation & Jacket:

• Insulation Material: Pvc-Polyvinyl Chloride
• Jacket Material: Pvc-Polyvinyl Chloride

Shielding:

• Shield: Yes
• Screen/Shield Type: FOIL SHIELDED - ALUM/MYLAR
• Shield Construction: OVERALL Shield & DRAIN

Ratings & Compliance:

• Voltage Rating: 300 V
• NEC rating: UL Listed Art 800
• Fire Rating: General Purpose
