Alpha Wire 5664 BK199, Communication Control Industrial Cable 4C 8 AWG 600 V

Part Number: 5664 BK199

Alpha Wire 5664 BK199 is a 4-Conductor industrial communication/Control Cable built for demanding motor supply and VNTC power applications. It features 8 AWG Stranded Bare Copper Conductors with PVC/nylon Insulation and a PVC Jacket for durable performance in industrial environments. The cable is rated 600V and includes a cabled core with clear Mylar tape wrap, plus an A/P/A tape Shield with Tinned Copper braid and drain wires. A black Outer Jacket and Alpha Wire Color Code KX Conductor Identification support consistent installation and maintenance.

General Specifications:

• Product Type: VNTC Power
• Voltage Range: 600V
• Armor: No
• Composite: No
• Earth/Ground Wires: No

Conductors:

• Number Of Conductors: 4 Conductor
• Conductor Size: 8 AWG
• Conductor Type: Stranded
• Conductor Material: Bare Copper
• Component Build: 4 X 1 Cond
• Conductor Construction: 8 (168(7x24)/30) AWG Bare Copper
• Conductor Diameter (In): 0.168

Insulation:

• Insulation Material: PVC/Nyl-Polyvinyl Chloride/Nylon
• Insulation Wall: 0.032" Wall, Nom. PVC/ 0.006" Wall NYLON
• Insulated Conductor Diameter (In): 0.244

Identification (Conductors):

• Conductor Print: Alphanumeric Numbers - 1-One Alternating And Inverted
• Color Code: Alpha Wire Color Code KX
• Conductor 1 Color: Green/Yellow
• Conductor 2 Color: Black#1
• Conductor 3 Color: Black#2
• Conductor 4 Color: Black#3

Cabling & Core Wrap:

• Cable Assembly: 4 Components Cabled
• Twists: 1.5 Twists/foot (min)
• Orientation: Components to be arranged from Inside Layer to Outside Layer
• Core Wrap: Clear Mylar Tape, 25% Overlap, Min.

Shielding:

• Shield: Unshielded
• Shield: A/P/A Tape, 25% Overlap, Min.
• Drain Wire: 4 x 14 (41/30) AWG Tinned Copper
• Braid: Tinned Copper,70% Coverage, Min.

Jacket:

• Jacket Material: PVC-Polyvinyl Chloride
• Jacket Wall: 0.063" Wall, Nom.,PVC
• Overall Diameter (In): 0.760+/- 0.028
• Jacket Color(s): Black
• Jacket Separator: Tissue Tape, 25% Overlap, Min.

Cable Marking (Factory Print):

• ALPHA WIRE-* P/N 5664 4C 8 AWG
  XTRAGUARD(R) MOTOR SUPPLY CABLE - EXXXXXX
  (UL) WTTC 1000V 90C OR (UL) TC-ER 600V 90C DRY
  75C WET SUN RES DIR BUR OR MTW 8 AWG
  OR CRU AWM I/II A/B 90C 600V FT4 CE
  ROHS (SEQ FOOTAGE)
  * = Factory Code
