Alpha Wire 5857 RD001, M16878E Type E Cable 1C 18 AWG 600V Fluoropolymer, Red

Part Number: 5857 RD001

Alpha Wire 5857 RD001 is a high-performance M16878E Type E Hookup wire designed for reliable electrical connections in demanding environments. It features an 18 AWG silver plated copper Conductor with PTFE Insulation for excellent temperature and chemical resistance, along with a 600V rating. Built to MIL-W-16878/4 (TYPE E) and UL TYPE AWM, STYLE 1213, this wire is a Solid choice for aerospace, defense, and industrial control wiring where consistent performance matters. It is Not Shielded and is available in multiple Standard Colors for easy circuit Identification.

Specifications:

• Mil spec: MIL-W-16878/4 (TYPE E)
• UL style: UL TYPE AWM, STYLE 1213
• Shielding: Not Shielded

Conductor:

• Conductor Material: Silver plated copper
• Conductor Size: 18 AWG (American Wire Gauge)
• Construction: 18 (19/30) AWG Silver Plated Copper
• Conductor Diameter: 0.050 (In)

Insulation:

• Insulation Material: TFE-TETRAFLUOROETHYLENE & PTFE
• Insulation: 0.010" Wall, Nom. PTFE, RED
• Insulated Diameter: 0.069+/- 0.005 (In)

Construction Details:

• Component: 1 X 1 Hookup

Available Colors:

• WHITE, BLACK, RED, GREEN, YELLOW, BLUE, BROWN
• ORANGE, SLATE, VIOLET
