Alpha Wire 6222C SL001, Communication Control Industrial Cable 2 Pair 24 AWG 300 V PVC

Part Number: 6222C SL001

Alpha Wire 6222C SL001 is a shielded communication and control industrial cable designed for reliable low-voltage signal transmission in electrically noisy environments. It features 24 AWG Stranded Tinned Copper Conductors with foamed polyethylene Insulation and an overall foil-and-Braid Shield for enhanced EMI/RFI protection. The cable is built with 2 x 1 PAIR components cabled together, includes a 24 (7/32) AWG Tinned Copper Drain Wire, and is finished with a slate PVC Jacket. Rated 300 V and marked for applications including (UL) TYPE CMG or AWM 2919, this cable is well-suited for industrial control, instrumentation, and computer cable runs where shielding and durability matter.

Conductors:

• Number Of Conductors: 3 Pairs
• Conductor Size: 24 AWG (American Wire Gauge)
• Conductor Stranding: 24 (7/32) AWG Tinned Copper
• Conductor Material: Tinned Copper
• Conductor Type: Stranded Conductor
• Conductor Diameter ("in"): 0.024

Insulation:

• Insulation Material: FPE-Foamed Polyethylene
• Insulation description: 0.0125" Wall, Nom. Polyethylene, Foam
• Insulated Conductor Diameter ("in"): 0.049

Pairing, Cabling, and Twists:

• Component build: 2 x 1 PAIR
• Pair construction: 2/Cond Cabled Together
• Pair twists: 9.6 Twists/foot (min.)
• Cable assembly: 2 Components Cabled
• Cable assembly twists: 4.8 Twists/foot (min.)
• Orientation: Components to be arranged from Inside Layer-to-Outside Layer

Shielding:

• Shielded: Yes
• Screen/Shield Type: Braid Over Foil Shield
• Shield Construction: Overall Foil & Braid
• Shield tape: Alum/Mylar Tape, 25% Overlap (min.)
• Foil direction: Foil Facing Out
• Drain Wire: 24 (7/32) AWG Tinned Copper
• Braid: Tinned Copper,65% Coverage (min.)

Jacket:

• Jacket Material: Pvc-Polyvinyl Chloride
• Jacket description: 0.035" Wall, Nom. PVC
• Overall Diameter ("in"): 0.270 (0.287 max.)
• Jacket Color: Slate

Color Code:

• Color code: Alpha Wire Color Code M
• Pair 1: BLUE/WHITE - WHITE/BLUE
• Pair 2: ORANGE/WHITE - WHITE/ORANGE

Ratings and Compliance:

• Voltage Rating: 300 V
• NEC rating: UL Listed Art 800
• Fire Rating: General Purpose

Cable Print (as marked):

• ALPHA WIRE-* P/N 6222C 2PR 24 AWG
  SHIELDED 75C (UL) TYPE CMG OR AWM 2919 LOW VOLTAGE
  COMPUTER CABLE --- LLXXXXXX CSA TYPE CMG 60C FT4
  CE ROHS
  * = Factory Code
  Note: Product may have c(UL) or CSA markings depending upon plant of manufacture.
