Alpha Wire 6328 SL001, Communication Control Industrial Cable 4C 24 AWG Shielded 300 V PVC

Part Number: 6328 SL001

Alpha Wire 6328 SL001 is a communication and control industrial cable built for reliable signal transmission in demanding environments. It features 4 Conductors of 24 AWG (American Wire Gauge) Stranded, Tinned Copper for flexibility and dependable conductivity. For noise reduction and improved performance in electrically noisy areas, it includes an overall foil & Braid Shield (braid over Foil Shield). The cable uses SRPVC-SEMI-RIGID POLYVINYL CHLORIDE Insulation with a Pvc-Polyvinyl Chloride Jacket and is rated 300 V with UL Listed Art 800 and a General Purpose Fire Rating.

Conductors:

• Number Of Conductors: 4 Conductors
• Conductor Size: 24 AWG (American Wire Gauge)
• Conductor Material: Tinned Copper
• Conductor Type: Stranded Conductor

Shielding:

• Shielded: YES
• Screen/Shield Type: BRAID OVER Foil Shield
• Shield Construction: OVERALL FOIL & BRAID

Materials:

• Insulation Material: SRPVC-SEMI-RIGID POLYVINYL CHLORIDE
• Jacket Material: Pvc-Polyvinyl Chloride

Ratings & Compliance:

• Voltage Rating: 300 V
• NEC Rating: UL Listed Art 800
• Fire Rating: General Purpose
