Alpha Wire 65003 SL001, Xtra Guard Flex Cable 3C 20 AWG Unshielded 600 V PVC

Part Number: 65003 SL001

Alpha Wire 65003 SL001 Xtra Guard Flex Cable is a flexible Control Cable built for demanding industrial applications requiring reliable performance up to 600V. It features 3 Conductors of 20 AWG Stranded Bare Copper with PVC Insulation and a PVC oil-resistant Jacket for durability in motion and harsh environments. This unshielded construction is cabled at 6.0 Twists/foot (min) and includes Conductor Identification with alphanumeric numbering plus distinct Conductor colors. It is RoHS compliant and listed to UL/CSA/CE with the manufacturer’s full Jacket print included below.

Electrical & Compliance:

• Voltage Range: 600V
• Standards: UL/CSA/CE
• RoHS Compliant: Yes

Conductors:

• Number Of Conductors: 3 Conductor
• Conductor Size: 20 AWG
• Conductor Stranding: 20 (10/30) AWG Bare Copper
• Conductor Material: Bare Copper
• Conductor Type: Stranded
• Earth/Ground Wires: No
• Conductor Diameter (In): 0.037

Insulation:

• Insulation Material: PVC-Polyvinyl Chloride
• Insulation Wall: 0.022" Wall, Nom. PVC
• Insulated Conductor Diameter (In): 0.081

Core Identification:

• Conductor Print: ALPHANUMERIC NUMBERS - 1-ONE ALTERNATING AND INVERTED
• Conductor Colors: 1: Black #1; 2: Black #2; 3: Yellow/Green

Cabling:

• Assembly: 3 Components Cabled
• Twists: 6.0 Twists/foot (min)
• Orientation: Components to be arranged from Inside Layer to Outside Layer

Jacket:

• Jacket Material: PVC-Polyvinyl Chloride
• Jacket Wall: 0.035" Wall, Nom.,PVC, Oil Resistant
• Overall Diameter (In): 0.251+/- 0.015
• Jacket Color: Slate
• Jacket Separator: Tissue Tape, 25% Overlap, Min.

Shielding:

• Shield: Unshielded

Product Type:

• Product Type: Flex Cont

Jacket Print (Factory Marking):

• ALPHA WIRE-* P/N 65003 3C 20 AWG
  XTRAGUARD(R) FLEXIBLE Control Cable RU AWM 2587
  CLASS K OR CRU AWM I/II A/B FT1 90C 600V
  CE ROHS (SEQ FOOTAGE)
  * = Factory Code
