Alpha Wire 65607 SL001, Xtra Guard Xtra Guard Flex 7C 16 AWG 600 V PVC

Part Number: 65607 SL001

Alpha Wire 65607 SL001 Xtra Guard Xtra Guard Flex is a flexible Control Cable built for demanding industrial wiring where durability and easy Identification matter. It features 7 Conductors of 16 AWG Stranded Bare Copper with PVC Insulation and a PVC oil-resistant Jacket, rated 600V and 90C. This unshielded construction is UL/CSA/CE compliant and RoHS compliant, with alphanumeric Conductor Identification and a slate Outer Jacket for a clean, professional install. A tissue tape Jacket separator and a 3.2 Twists/foot (min) cabling lay help support consistent handling and performance.

Electrical & Compliance:

• Voltage Range: 600V
• Standards: UL/CSA/CE
• RoHS Compliant: Yes

Conductors:

• Number Of Conductors: 7 Conductor
• Conductor Size: 16 AWG
• Conductor Stranding: 16 (26/30) AWG Bare Copper
• Conductor Material: Bare Copper
• Conductor Type: Stranded
• Earth/Ground Wires: No
• Conductor Diameter: 0.060 (In)

Insulation:

• Insulation Material: PVC-Polyvinyl Chloride
• Insulation Wall: 0.022" Wall, Nom. PVC
• Insulated Conductor Diameter: 0.104 (In)

Cabling:

• Assembly: 7 Components Cabled
• Twists: 3.2 Twists/foot (min)
• Orientation: Components to be arranged from Inside Layer to Outside Layer

Jacket:

• Jacket Material: PVC-Polyvinyl Chloride
• Jacket Wall: 0.035" Wall, Nom.,PVC, Oil Resistant
• Overall Diameter: 0.390+/- 0.020 (In)
• Jacket Color: Slate
• Jacket Separator: Tissue Tape, 25% Overlap, Min.

Shielding:

• Shield: Unshielded

Product Type:

• Product Type: Flex Cont

Conductor Identification:

• Conductor Print: ALPHANUMERIC NUMBERS - 1-ONE ALTERNATING AND INVERTED
• Conductor Colors: BLACK #1, BLACK #2, BLACK #3, BLACK #4, BLACK #5, BLACK #6, YELLOW/GREEN

Cable Print:

• ALPHA WIRE-* P/N 65607 7C 16 AWG
  XTRAGUARD(R) FLEXIBLE Control Cable RU AWM 2587
  CLASS K OR CRU AWM I/II A/B FT1 90C 600V
  CE ROHS (SEQ FOOTAGE)
  * = Factory Code
