Alpha Wire 6622 WH001, Communication Control Industrial Cable 2C 24 AWG 600 V PVC

Part Number: 6622 WH001

Alpha Wire 6622 WH001 is a 2-Conductor communication and control industrial cable built with 24 AWG Stranded Tinned Copper Conductors and a durable PVC Jacket. It uses irradiated PVC Insulation and features a cabled pair construction with 9.6 Twists/foot (min) for consistent performance in control and signal applications. The Jacket is WHITE and includes a Clear Mylar Tape core wrap with 25% Overlap, Min. for added stability. Factory print markings include ALPHA WIRE-* P/N 6622 and compliance identifiers as printed.

Conductors:

• Number Of Conductors: 2 Conductors
• Conductor Size: 24 AWG (American Wire Gauge)
• Conductor Stranding/Type: Stranded Conductor
• Conductor Material: Tinned Copper
• Conductor Construction: 24 (7/32) AWG Tinned Copper
• Conductor Diameter (In): 0.024

Insulation:

• Insulation Material: IRPVC-IRRADIATED CROSS-LINKED POLYVINYL CHLORIDE
• Insulation Description: 0.010" Wall, Nom. PVC, Irradiated
• Insulated Conductor Diameter (In): 0.044
• Color Code Standard: Alpha Wire Color Code G
• Conductor Colors: 1 = WHITE; 2 = BLACK

Cabling & Core Wrap:

• Cable Assembly: 2 Components Cabled
• Twists: 9.6 Twists/foot (min)
• Orientation: Components to be arranged from Inside Layer to Outside Layer
• Core Wrap: Clear Mylar Tape, 25% Overlap, Min.

Jacket:

• Jacket Material: Pvc-Polyvinyl Chloride
• Jacket Description: 0.032" Wall, Nom.,PVC
• Overall Diameter (In): 0.155 (0.165 Max.)
• Jacket Color(s): WHITE
• Print: ALPHA WIRE-* P/N 6622
  RU AWM 2576 VW-1 80C 150V CE ROHS
  * = Factory Code

Ratings & Shielding:

• Voltage: 600 V
• Fire Rating: General Purpose
• Screen/Shield: No
