Alpha Wire 6715 RD001, EcoWire Hook Up Wire 18 AWG 600 V mPPE Insulation

Part Number: 6715 RD001

Alpha Wire 6715 RD001 EcoWire hook up wire is a flexible, RoHS-compliant lead wire built with 18 AWG Tinned Copper and durable MPPE-modified polyphenylene Insulation. It is rated 105 Degrees Centigrade (221 F) and 600 V, making it well-suited for internal wiring and general-purpose electrical applications where heat and voltage performance matter. This wire is Not Shielded and is supplied in a red Insulation Color. It is produced under UL Type AWM, Style 11028 and falls within the UL Style 10000 Series.

Conductor:

• Conductor Material: Tinned Copper
• Conductor Size: 18 AWG (American Wire Gauge)
• Conductor Stranding: 16 strands in each Conductor
• Construction (Conductor): 18 (16/30) AWG Tinned Copper
• Conductor Diameter (In): 0.048

Insulation:

• Insulation Material: MPPE-modified polyphenylene
• Insulation Color: Red
• Insulation wall: 0.0095" Wall, Nom. MPPE
• Insulation Diameter (In): 0.067+/- 0.002

Electrical & Temperature Ratings:

• Voltage Rating: 600 V
• Temperature Rating: 105 Degrees Centigrade (221 F)

Compliance & Approvals:

• UL style: UL TYPE AWM, STYLE 11028
• Product type: UL Style 10000 Series
• RoHS compliant: Yes

Shielding:

• Shielded: Not Shielded

Construction Overview:

• Component: 1 X 1 Hookup

Cable Print (as marked):

• ALPHA WIRE ECOWIRE TM 18 AWG E163869-*
• RU AWM 11028 105C 600V VW-1 --- CRU AWM I A/B
• 105C 600V FT1 CE ROHS
• {0} * = Factory Code

Available Color(s) (manufacturer list):

• WHITE, BLACK, RED, GREEN, YELLOW, BLUE, BROWN
• ORANGE, SLATE, VIOLET, GREEN/YELLOW, DARK BLUE
• WHITE/BLUE
