Alpha Wire 6715 WH001, EcoWire Hook Up Wire 18 AWG 600 V mPPE Insulation

Part Number: 6715 WH001

Alpha Wire 6715 WH001 EcoWire hook up wire is a flexible 18 AWG lead designed for reliable internal wiring where durability and compliance matter. It features a Tinned Copper Conductor with 16 strands and MPPE-modified polyphenylene Insulation in white for clean Identification in panels and equipment. Rated 600 V and 105 Degrees Centigrade (221 F), it supports demanding electrical environments while remaining RoHS compliant. This wire is Not Shielded and is built to UL Type AWM, Style 11028 requirements.

Construction:

• Component: 1 X 1 Hookup
• Conductor: 18 (16/30) AWG Tinned Copper
• Conductor Stranding: 16 strands in each Conductor
• Conductor Diameter (In): 0.048
• Insulation: 0.0095" Wall, Nom. MPPE
• Insulation Diameter (In): 0.067+/- 0.002

Electrical & Temperature Ratings:

• Voltage Rating: 600 V
• Temperature Rating: 105 Degrees Centigrade (221 F)

Materials:

• Conductor Material: Tinned Copper
• Insulation Material: MPPE-modified polyphenylene

Compliance & Approvals:

• UL style: UL TYPE AWM, STYLE 11028
• Product type: UL Style 10000 Series
• RoHS compliant: Yes

Shielding:

• Shielded: Not Shielded

Color:

• Insulation Color: White
• Available color(s): WHITE, BLACK, RED, GREEN, YELLOW, BLUE, BROWN ORANGE, SLATE, VIOLET, GREEN/YELLOW, DARK BLUE WHITE/BLUE

Cable Print (as marked):

• ALPHA WIRE ECOWIRE TM 18 AWG E163869-*
  RU AWM 11028 105C 600V VW-1 --- CRU AWM I A/B
  105C 600V FT1 CE ROHS
  {0} * = Factory Code
