Alpha Wire 6717 GY001, EcoWire Hook Up Wire 14 AWG 600 V mPPE Insulation

Part Number: 6717 GY001

Alpha Wire 6717 GY001 EcoWire hook up wire is a 14 AWG, 600 V lead designed for reliable internal wiring in control panels, appliances, and general equipment. It features a Tinned Copper Conductor with 41 strands in each Conductor for flexibility, paired with MPPE-modified polyphenylene Insulation. This wire is rated to 105 Degrees Centigrade (221 F) and is Not Shielded, making it a strong fit for compact, high-performance wiring runs. It is RoHS compliant and built to UL TYPE AWM, STYLE 11028 requirements.

Construction:

• Component: 1 X 1 Hookup
• Conductor: 14 (41/30) AWG Tinned Copper
• Insulation: 0.011" Wall, Nom. MPPE

Materials:

• Conductor Material: Tinned Copper
• Insulation Material: MPPE-modified polyphenylene

Electrical & Temperature Ratings:

• Voltage Rating: 600 V
• Temperature Rating: 105 Degrees Centigrade (221 F)

Dimensions (Diameters (In)):

• Conductor Diameter: 0.074
• Insulation Diameter: 0.096+/- 0.002

Compliance & Standards:

• Product type: UL Style 10000 Series
• UL style: UL TYPE AWM, STYLE 11028
• RoHS compliant: Yes

Shielding:

• Shielded: Not Shielded

Color:

• Insulation Color: Green with a yellow stripe
• Color(s): WHITE, BLACK, RED, GREEN, YELLOW, BLUE, BROWN ORANGE, SLATE, VIOLET, GREEN/YELLOW, DARK BLUE WHITE/BLUE, PINK

Cable Print (As Marked):

• ALPHA WIRE ECOWIRE TM 14 AWG E163869-*
  RU AWM 11028 105C 600V VW-1 --- CRU AWM I A/B
  105C 600V FT1 CE ROHS
  {0} * = Factory Code
