Alpha Wire 6718 GY001, EcoWire Hook Up Wire 12 AWG 600 V MPPE Insulation

Part Number: 6718 GY001

Alpha Wire 6718 GY001 EcoWire hook up wire is a 12 AWG, 600 V lead designed for reliable internal wiring in panels, equipment, and general electrical applications. It features a Tinned Copper Conductor with 65 strands in each Conductor for flexibility, paired with MPPE-modified polyphenylene Insulation. This wire is UL type AWM, style 11028 and is rated to 105 Degrees Centigrade (221 F). It is RoHS compliant and Not Shielded, with a green with a yellow stripe Insulation Color.

Conductor:

• Conductor Material: Tinned Copper
• Conductor Size: 12 AWG (American Wire Gauge)
• Conductor Stranding: 65 strands in each Conductor
• Construction (Conductor): 12 (65/30) AWG Tinned Copper
• Conductor Diameter (in): 0.093

Insulation:

• Insulation Material: MPPE-modified polyphenylene
• Insulation wall: 0.012" Wall, Nom. MPPE
• Insulation Color: Green with a yellow stripe
• Insulation Diameter (in): 0.117+/- 0.002

Electrical & Temperature Ratings:

• Voltage Rating: 600 V
• Temperature Rating: 105 Degrees Centigrade (221 F)

Compliance, Type & Shielding:

• Product type: UL style 10000 series
• UL style: UL type AWM, style 11028
• RoHS compliant: Yes
• Shielding: Not Shielded

Construction Overview:

• Component: 1 X 1 Hookup

Cable Print (as marked):

• ALPHA WIRE ECOWIRE TM 12 AWG E163869-*
  RU AWM 11028 105C 600V VW-1 --- CRU AWM I A/B
  105C 600V FT1 CE ROHS
  {0} * = Factory Code

Available Colors (manufacturer listing):

• WHITE, BLACK, RED, GREEN, YELLOW, BLUE, BROWN ORANGE, SLATE, VIOLET, GREEN/YELLOW, DARK BLUE
