Alpha Wire 7054/19 RD001, Premium Hook Up Wire 24 AWG 150 V IRRPVC Insulation

Part Number: 7054/19 RD001

Alpha Wire 7054/19 RD001 is a premium hook up wire built with a 24 AWG Tinned Copper Conductor and durable IRPVC-irradiated polyvinyl chloride Insulation. It is rated 150 V and supports a Temperature Rating of 105 Degrees Centigrade (221 F), making it well-suited for internal wiring and general electrical applications where heat resistance and flexibility are important. This wire is Not Shielded and features 19 strands in each Conductor for improved handling. It meets MIL-W-16878/1 (Type B) and is listed as UL Type AWM, Style 1429, with manufacturer print markings shown below exactly as provided.

Conductor:

• Number Of Conductors: 1 X 1 Hookup
• Conductor Size: 24 AWG (American Wire Gauge)
• Conductor Stranding: 19 strands in each Conductor
• Conductor Construction: 24 (19/36) AWG Tinned Copper
• Conductor Material: Tinned Copper
• Conductor Diameter (In): 0.025

Insulation:

• Insulation Material: IRPVC-Irradiated Polyvinyl Chloride
• Insulation construction: 0.010" Wall, Nom. PVC, Irradiated
• Insulation Color: Red
• Insulation Diameter (In): 0.045+/- 0.002

Electrical & Temperature Ratings:

• Voltage Rating: 150 V
• Temperature Rating: 105 Degrees Centigrade (221 F)

Compliance & Approvals:

• UL style: UL Type AWM, Style 1429
• Product type: UL Styles 1000-1999
• Mil spec: MIL-W-16878/1 (Type B)
• RoHS compliant: Not declared

Shielding:

• Shielded: Not Shielded

Manufacturer Cable Print (as provided):

• ALPHA WIRE-*
  E163869 RU AWM 1429 80C 150V VW-1
  LLXXXXXX CSA AWM I A/B 80C 150V FT1 ROHS
  * = Factory Code
  [Note: Product may have c(UL) or CSA markings depending upon plant of manufacture.]

Available Color(s) (as provided):

• WHITE, BLACK, RED, GREEN, YELLOW, BLUE, BROWN
  ORANGE, SLATE, VIOLET
