Alpha Wire 86207CY SL001, Composite Cable 7C 24 AWG Shielded PVC Jacket

Part Number: 86207CY SL001

Alpha Wire 86207CY SL001 is a composite cable designed for reliable signal and control wiring where shielding is required. It features 7 Conductors made from Tinned Copper with a Stranded construction for flexibility during installation. For noise reduction, it includes a braid over Foil Shield with an overall Shield and drain. The cable uses SRPVC-semi-rigid polyvinyl chloride Insulation and a PVC-polyvinyl chloride Jacket, and it is rated for General Purpose applications.

Conductors:

• Number Of Conductors: 7 Conductors
• Conductor Size: 24 AWG (American Wire Gauge)
• Conductor Material: Tinned Copper
• Conductor Type: Stranded Conductor

Shielding:

• Shielded: Yes
• Screen/Shield Type: Braid over Foil Shield
• Shield Construction: Overall Shield & drain

Materials:

• Insulation Material: SRPVC-semi-rigid polyvinyl chloride
• Jacket Material: PVC-polyvinyl chloride

Ratings:

• Fire Rating: General Purpose
