Belden 1032A 010, Power Limited Tray Cable 1 Pair 18 AWG 300V PVC, Black Jacket
Description
Belden 1032A 010 is a power limited tray cable designed for industrial control and instrumentation wiring in raceways, cable trays, and ducts. It is built with 1 pair of 18 AWG (7x26) BC - Bare Copper stranded conductors with PVC - Polyvinyl Chloride insulation and an overall aluminum mylar foil shield with 100% coverage. The cable uses a black PVC - Polyvinyl Chloride outer jacket with ripcord and is rated 300 V (PLTC, CMG, AWM 2464), 150 V (ITC) with an operating range of -30°C to +105°C. Environmental suitability includes Indoor/Outdoor, Indoor, Outdoor, Sunlight Resistance.
Belden 1032A 010 Key Features
- Power limited tray cable for industrial control and instrumentation wiring in raceways, cable trays, and ducts.
- 1 pair of 18 AWG (7x26) BC - Bare Copper stranded conductors with PVC - Polyvinyl Chloride insulation.
- Overall aluminum mylar foil shield with 100% coverage and a 20 AWG (7x28) TC drainwire.
- Black PVC - Polyvinyl Chloride outer jacket with ripcord; armor: No.
- UL voltage rating: 300 V (PLTC, CMG, AWM 2464), 150 V (ITC).
- Operating: -30°C to +105°C; UL temperature: 105°C.
- Environmental suitability: Indoor/Outdoor, Indoor, Outdoor, Sunlight Resistance.
- Flammability / reaction to fire: UL 1685 FT4 Loading, FT4, IEEE 1202 FT4.
- NEC / UL compliance: Article 725, Article 727, Article 800, CMG, ITC, PLTC, CL3.
Belden 1032A 010 Applications
- Supports industrial control and instrumentation wiring where consistent signal performance is needed in control circuits.
- Installs in raceways, cable trays, and ducts in industrial environments.
- Fits digital control and low voltage digital control (24v, …) connections in automation systems.
- Pairs with instruments (4-20ma, 0-10v, ...) to transmit control and measurement signals.
- Supports distributed control system (DCS) and programmable logic controller (PLC) wiring in industrial control panels and systems.
- Works in control circuits for encoders and other feedback devices used in automation.
- Connects solenoids, valves, actuators, and positioners in control and instrumentation setups.
Belden™ and all associated trademarks are the property of their respective owners.
Specifications
| Attribute | Value |
|---|---|
| Number of pairs | 1 |
| Conductor Type | Stranded Conductor |
| Insulation thickness (nom.) | 0.017 in (0.43 mm) |
| Insulation diameter (nom.) | 0.080 in (2.0 mm) |
| Color Code | ICEA Chart E1 |
| Shield Type | Tape |
| Shield Material | Bi-Laminate (Alum+Poly) |
| Jacket thickness (nom.) | 0.037 in (0.94 mm) |
| Overall cable diameter (nominal) | 0.237 in (6.02 mm) |
| Bulk cable weight | 30 lbs/1000ft |
| Nom. conductor DCR | 5.86 Ohm/1000ft |
| Nom. outer shield DCR | 12.8 Ohm/1000ft (42.0 Ohm/km) |
| Nom. capacitance cond-to-cond | 51 pF/ft (170 pF/m) |
| Nom. capacitance cond-to-other (conds + Shield) | 95 pF/ft (310 pF/m) |
| Nom. inductance | 0.19 μH/ft (0.62 μH/m) |
| Max. current | 14 Amps per Conductor @ 30°C |
| Bend radius (stationary min.) | 2.8 in (71 mm) |
| Bend radius (installation min.) | 2.8 in (71 mm) |
| Max Pull Tension | 58 lbs (26 kg) |
| AWM compliance | AWM 2464 |
| CEC / C(UL) compliance | CMG |
| European directive compliance | EU CE Mark, EU Directive 2015/863/EU (RoHS 2 amendment), EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE) |
| APAC compliance | China RoHS II (GB/T 26572-2011) |
| Item Type | Belden Instrumentation Cable, PLTC |
| Other Part Numbers | 1032A 0101000, 1032A 010, 1032A 010100, 1032A 010250, 1032A 010500 |
| Priced Per | FT |
