Belden 10GX53F 009, UTP Cat 6A 4PR 23AWG CMP Plenum White
Description
Belden 10GX53F 009 is a 10GX Category 6A Enhanced premise horizontal cable (625MHz) designed for Ethernet up to 10GBASE-T in plenum, indoor spaces. It is a 4 pair, 23 AWG solid bare copper F/UTP cable with a tape shield and a Plenum-CMP Flamarrest® PVC-LS jacket. The design includes a center member (Patented EquiSpline®) and is rated 300 V (CMP), 300 V (CL3P) with UL temperature 105°C.
Belden 10GX53F 009 Key Features
- Category 6A Enhanced premise horizontal cable (625MHz) for high-performance structured cabling.
- Supports Ethernet up to 10GBASE-T for modern network links.
- 4 pair, 23 AWG solid bare copper F/UTP construction for consistent conductor geometry.
- Tape shield with Bi-Laminate (Alum+Poly) and 100% coverage to help reduce noise in demanding environments.
- Plenum-CMP Flamarrest® PVC-LS jacket for plenum, indoor installations.
- Center member (Patented EquiSpline®) to help maintain cable geometry.
Belden 10GX53F 009 Applications
- Designed for premise horizontal cable runs in structured cabling systems.
- Enables Ethernet up to 10GBASE-T for high-speed network connectivity.
- Commonly used in Wi-Fi 6 and Wi-Fi 5 network deployments.
- Works well for surveillance connections where reliable data transport is required.
- Used for HDBaseT links in AV installations.
- Supports PoE++, PoE+, and PoE to deliver power and data over the same cabling.
- Intended for noisy environments where shielding can help manage interference.
Belden™ and all associated trademarks are the property of their respective owners.
Specifications
| Attribute | Value |
|---|---|
| Data category | Category 6A |
| Conductor stranding | Solid |
| Conductor Material | BC - Bare Copper |
| Insulation Material | FEP - Fluorinated Ethylene Propylene |
| Color Code | White & Blue, White & Orange, White & Green, White & Brown |
| Shield Material | Bi-Laminate (Alum+Poly) |
| Shield Coverage | 100% |
| Drainwire type | 26 AWG (7x34) TC |
| Jacket Material | PVC - Polyvinyl Chloride |
| Jacket trade name | Flamarrest® |
| Jacket Color | White |
| Overall cable diameter (nominal) | 0.275 in (6.99 mm) |
| Non-Plenum number | 10GX52F |
| Max. Conductor DCR | 82 Ohm/km (25 Ohm/1000ft) |
| Max. capacitance unbalance | 90 pF/100m |
| Delay (100 MHz) max. | 537.6 ns/100m |
| Delay skew (100 MHz) max. | 45 ns/100m |
| Nom. velocity of prop. | 68% |
| UL Voltage Rating | 300 V (CMP), 300 V (CL3P) |
| Operating temperature | -20°C To +75°C |
| Installation temperature | 0°C To +50°C |
| Storage temperature | -20°C To +75°C |
| Bend radius (stationary min.) | 2.25 in (57.2 mm) |
| Bend radius (installation min.) | 2.75 in (69.9 mm) |
| Max Pull Tension | 25 lbs (11 kg) |
| Bulk cable weight | 38 lbs/1000ft |
| Flammability / reaction to fire | NFPA 262, UL 910 (Plenum), FT6, IEC 60332-1-2 |
| CPR compliance | CPR Euroclass: Eca; CPR UKCA Class: Eca |
| NEC / UL compliance | Article 800, CMP, CMP-LP (0.7A), CL3P-LP (0.7A) |
| CEC / C(UL) compliance | CMP |
| ICEA compliance | S-116-732 |
| IEEE compliance | IEEE 802.3bt Type 1, Type 2, Type 3, Type 4 |
| NEMA Compliance | ANSI/NEMA WC-66 |
| TIA/EIA compliance | ANSI/TIA-568.2-D Category 6A |
| ISO/IEC compliance | ISO/IEC 11801-1, IEC 61156-5 |
| European directive compliance | EU CE Mark, EU Directive 2015/863/EU (RoHS 2 amendment), REACH, EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE), REACH: 2020-01-16 |
| UK regulation compliance | UKCA Mark |
| APAC compliance | China RoHS II (GB/T 26572-2011) |
| Other standard compliance(s) | NFPA 130 |
| Patent info | This product has one or more applicable patents. More information on patents can be found at https://www.belden.com/patents . |
| Priced Per | FT |
Images are for reference only. Specifications may change without notice — verify suitability for your application before purchase. The manufacturer's documentation controls.
