Belden 10GXS12005A1000, Copper Cable Cat6A 4PR 23 AWG CMR Green
SKU:Belden 10GXS12005A1000
● In stock
× 1,000 ft = Total: 1,000 ft
Description
Belden 10GXS12005A1000 is a 10GXS Category 6A Enhanced Premise Horizontal Cable (625MHz) designed for high-performance Ethernet up to 10GBASE-T in demanding indoor Riser installations. It features 4 pair of 23 AWG solid bare copper conductors in a U/UTP construction with a green PVC jacket. The design includes a center member (Patented EquiSpline®) and EquiBlock™ Barrier Technology to help maintain consistent performance in noisy environments and backbone runs.
Belden 10GXS12005A1000 Key Features
- This is a 10GXS Category 6A Enhanced Premise Horizontal Cable (625MHz) for Ethernet up to 10GBASE-T.
- It uses a U/UTP construction with 4 pair of 23 AWG solid bare copper conductors.
- It has a PVC - Polyvinyl Chloride jacket in green with Fire Rating: Riser-CMR.
- It includes a center member (Patented EquiSpline®) and EquiBlock™ Barrier Technology.
- Environmental suitability is Riser, Indoor.
Belden 10GXS12005A1000 Applications
- It is intended for premise horizontal cable installations.
- Ethernet up to 10GBASE-T is supported.
- Wi-Fi 6 and Wi-Fi 5 network deployments are listed.
- PoE++, PoE+, and PoE applications are listed.
- Use is suited for noisy environments.
- Data center EoR and MoR deployments are suited.
- Network backbone runs are suited.
- HDBaseT and HDBaseT 4K UHD are listed.
Patent Notice
- This product has one or more applicable patents. More information on patents can be found at https://www.belden.com/patents.
Belden™ and all associated trademarks are the property of their respective owners.
Specifications
| Attribute | Value |
|---|---|
| Type | Data |
| Insulation Material | PO - Polyolefin |
| Color Code | White & Blue, White & Orange, White & Green, White & Brown |
| Ripcord | Yes |
| Overall cable diameter (nominal) | 0.275 in (6.99 mm) |
| Plenum number | 10GXS13 |
| Max. Conductor DCR | 82 Ohm/km (25 Ohm/1000ft) |
| Max. capacitance unbalance | 45 pF/100m |
| UL Voltage Rating | 300 V (CMR), 300 V (CL3R) |
| Max. delay (at 100 MHz) | 537.6 ns/100m |
| Max. delay skew (at 100 MHz) | 45 ns/100m |
| Typical delay skew (at 100 MHz) | 30 ns/100m |
| Nom. velocity of prop. | 65% |
| UL temperature | 90°C |
| Operating temperature | -20°C To +75°C |
| Installation temperature | 0°C To +50°C |
| Storage temperature | -20°C To +75°C |
| Bend radius (stationary min.) | 1.25 in (31.8 mm) |
| Bend radius (installation min.) | 2.75 in (69.9 mm) |
| Max Pull Tension | 25 lbs (11 kg) |
| Bulk cable weight | 35 lbs/1000ft |
| Flammability / reaction to fire | UL 1666 Riser, FT4, IEC 60332-1-2 |
| CPR compliance | CPR Euroclass: Eca; CPR UKCA Class: Eca |
| NEC / UL compliance | Article 800, CMR, CMR-LP (0.6A), CL3R-LP (0.6A) |
| CEC / C(UL) compliance | CMR |
| ICEA compliance | S-116-732 |
| IEEE compliance | IEEE 802.3bt Type 1, Type 2, Type 3, Type 4 |
| NEMA Compliance | ANSI/NEMA WC-66 |
| TIA/EIA compliance | ANSI/TIA-568.2-D Category 6A |
| ISO/IEC compliance | ISO/IEC 11801-1, IEC 61156-5 |
| CENELEC compliance | Segregation class according EN50174-2 = a |
| European directive compliance | EU CE Mark, EU Directive 2015/863/EU (RoHS 2 amendment), REACH, EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE), REACH: 2020-01-16 |
| UK regulation compliance | UKCA Mark |
| APAC compliance | China RoHS II (GB/T 26572-2011) |
| Sustainability | Product Lens™, Environmental Product Declaration (EPD) Available |
| Priced Per | FT |
Images are for reference only. Specifications may change without notice — verify suitability for your application before purchase. The manufacturer's documentation controls.
