Belden 10GXS13 004, Copper Cable Cat6A 4PR 23 AWG CMP Yellow
SKU:Belden 10GXS13 004
● In stock
× 1,000 ft = Total: 1,000 ft
Description
Belden 10GXS13 004 is a Category 6A enhanced premise horizontal cable (625MHz) for Ethernet up to 10GBASE-T. It is built with 4 pairs of 23 AWG solid BC - Bare Copper conductors in a U/UTP construction. This Plenum-CMP cable features a Flamarrest® PVC-LS Jacket and a center member (Patented EquiSpline®) with EquiBlock™ Barrier Technology. It is specified with UL Voltage Rating: 300 V (CMP), 300 V (CL3P) and UL temperature: 105°C.
Belden 10GXS13 004 Key Features
- Category 6A enhanced premise horizontal cable (625MHz) designed for Ethernet up to 10GBASE-T.
- 4 pairs of 23 AWG solid BC - Bare Copper conductors in a U/UTP construction.
- Plenum-CMP rated with a Flamarrest® PVC-LS Jacket for indoor plenum use.
- Center member (Patented EquiSpline®) with EquiBlock™ Barrier Technology and a ripcord (Yes).
- Supports IEEE 802.3bt Type 1, Type 2, Type 3, Type 4 and NEC / UL compliance: CMP-LP (0.7A), CL3P-LP (0.7A).
Belden 10GXS13 004 Applications
- Use it in premise horizontal cable installations where Category 6A performance is required.
- Support Ethernet up to 10GBASE-T for high-speed network links.
- Connect Wi-Fi 6 and Wi-Fi 5 network infrastructure.
- Deploy it for PoE++, PoE+, and PoE installations.
- Choose it for noisy environments where maintaining signal integrity is important.
- Specify it for data center EoR and MoR layouts.
- Run it in network backbone paths within structured cabling systems.
- Enable HDBaseT and HDBaseT 4K UHD connectivity.
Belden™ and all associated trademarks are the property of their respective owners.
Specifications
| Attribute | Value |
|---|---|
| Data category | Category 6A |
| Number of pairs | 4 |
| Conductor size | 23 AWG |
| Conductor stranding | Solid |
| Conductor Material | BC - Bare Copper |
| Shielding type | U/UTP |
| Insulation Material | FEP - Fluorinated Ethylene Propylene |
| Color Code | White & Blue, White & Orange, White & Green, White & Brown |
| Jacket Material | PVC - Polyvinyl Chloride |
| Jacket trade name | Flamarrest® |
| Jacket type | Flamarrest® PVC-LS Jacket |
| Jacket rating | Plenum-CMP |
| Jacket Color | Yellow |
| Overall cable diameter (nominal) | 0.265 in (6.73 mm) |
| Max. Conductor DCR | 82 Ohm/km (25 Ohm/1000ft) |
| Max. capacitance unbalance | 45 pF/100m |
| Delay (100 MHz) max. | 537.6 ns/100m |
| Delay skew (100 MHz) max. | 45 ns/100m |
| Delay skew (100 MHz) typical | 30 ns/100m |
| Nom. velocity of prop. (100 MHz) | 69% |
| UL Voltage Rating | 300 V (CMP), 300 V (CL3P) |
| UL temperature | 105°C |
| Operating temperature | -20°C To +75°C |
| Installation temperature | 0°C To +50°C |
| Storage temperature | -20°C To +75°C |
| Bend radius (stationary min.) | 1.25 in (31.8 mm) |
| Bend radius (installation min.) | 2.75 in (69.9 mm) |
| Max Pull Tension | 25 lbs (11 kg) |
| Bulk cable weight | 37 lbs/1000ft |
| Flammability / reaction to fire | NFPA 262, UL 910 (Plenum), FT6, IEC 60332-1-2 |
| NEC / UL compliance | Article 800, CMP, CMP-LP (0.7A), CL3P-LP (0.7A) |
| CEC / C(UL) compliance | CMP |
| ICEA compliance | S-116-732 |
| IEEE compliance | IEEE 802.3bt Type 1, Type 2, Type 3, Type 4 |
| NEMA Compliance | ANSI/NEMA WC-66 |
| TIA/EIA compliance | ANSI/TIA-568.2-D Category 6A |
| ISO/IEC compliance | ISO/IEC 11801-1, IEC 61156-5 |
| CENELEC compliance | Segregation class according EN50174-2 = a |
| CPR compliance | CPR Euroclass: Eca; CPR UKCA Class: Eca |
| European directive compliance | EU CE Mark, EU Directive 2015/863/EU (RoHS 2 amendment), REACH, EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE), REACH: 2020-01-16 |
| UK regulation compliance | UKCA Mark |
| APAC compliance | China RoHS II (GB/T 26572-2011) |
| Sustainability | Product Lens™, Environmental Product Declaration (EPD) Available |
| Non-Plenum number | 10GXS12 |
| Patents info | This product has one or more applicable patents. More information on patents can be found at https://www.belden.com/patents . |
| Priced Per | FT |
Images are for reference only. Specifications may change without notice — verify suitability for your application before purchase. The manufacturer's documentation controls.
