Belden 10GXS13 005, Copper Cable Cat6A 4PR 23 AWG CMP Green
SKU:Belden 10GXS13 005
● In stock
× 1,000 ft = Total: 1,000 ft
Description
Belden 10GXS13 005 is a Category 6A Enhanced Premise Horizontal Cable (625MHz) designed for indoor plenum installations. This U/UTP data cable uses 4 pair of 23 AWG solid bare copper conductors with FEP - Fluorinated Ethylene Propylene insulation and a Flamarrest® PVC-LS jacket in Green. It is specified for Ethernet up to 10GBASE-T and references support for Wi-Fi 6, PoE++, PoE+, and PoE.
Belden 10GXS13 005 Key Features
- Category 6A Enhanced Premise Horizontal Cable (625MHz) for structured cabling data networks.
- U/UTP construction specified for Category 6A data cabling.
- 4 pair of 23 AWG solid bare copper conductors.
- FEP - Fluorinated Ethylene Propylene insulation with color code: White & Blue, White & Orange, White & Green, White & Brown.
- Plenum-rated jacket system: Plenum-CMP, Flamarrest® PVC-LS, jacket color Green.
- UL voltage rating: 300 V (CMP), 300 V (CL3P).
- Environmental suitability listed as plenum, indoor.
Belden 10GXS13 005 Applications
- Use in premise horizontal cabling where a Category 6A Enhanced Premise Horizontal Cable (625MHz) is specified.
- Support Ethernet up to 10GBASE-T for high-speed network links.
- Deploy in Wi-Fi 6 and Wi-Fi 5 network installations.
- Deliver power over the network, including PoE++, PoE+, and PoE.
- Install in noisy environments where network cabling is required.
- Reference for data center layouts including EoR and MoR.
- Use for network backbone connections within a structured cabling system.
- Specify for HDBaseT and HDBaseT 4K UHD deployments.
Belden™ and all associated trademarks are the property of their respective owners.
Specifications
| Attribute | Value |
|---|---|
| Type | Data |
| Data category | Category 6A |
| Jacket Material | PVC - Polyvinyl Chloride |
| Separator | Center Member (Patented EquiSpline®), EquiBlock™ Barrier Technology |
| Ripcord | Yes |
| Non-Plenum number | 10GXS12 |
| Overall cable diameter (nominal) | 0.265 in (6.73 mm) |
| Max Pull Tension | 25 lbs (11 kg) |
| Bulk cable weight | 37 lbs/1000ft |
| Bend radius (stationary min.) | 1.25 in (31.8 mm) |
| Bend radius (installation min.) | 2.75 in (69.9 mm) |
| Max. Conductor DCR | 82 Ohm/km (25 Ohm/1000ft) |
| Max. capacitance unbalance | 45 pF/100m |
| Nom. velocity of prop. | 69% |
| Max. Delay (100 MHz) | 537.6 ns/100m |
| Max. delay skew (100 MHz) | 45 ns/100m |
| Typical delay skew (100 MHz) | 30 ns/100m |
| UL temperature | 105°C |
| Operating | -20°C To +75°C |
| Installation | 0°C To +50°C |
| Storage | -20°C To +75°C |
| Flammability / reaction to fire | NFPA 262, UL 910 (Plenum), FT6, IEC 60332-1-2 |
| NEC / UL compliance | Article 800, CMP, CMP-LP (0.7A), CL3P-LP (0.7A) |
| CEC / C(UL) compliance | CMP |
| CPR compliance | CPR Euroclass: Eca; CPR UKCA Class: Eca |
| TIA/EIA compliance | ANSI/TIA-568.2-D Category 6A |
| ISO/IEC compliance | ISO/IEC 11801-1, IEC 61156-5 |
| IEEE compliance | IEEE 802.3bt Type 1, Type 2, Type 3, Type 4 |
| ICEA compliance | S-116-732 |
| NEMA Compliance | ANSI/NEMA WC-66 |
| CENELEC compliance | Segregation class according EN50174-2 = a |
| European directive compliance | EU CE Mark, EU Directive 2015/863/EU (RoHS 2 amendment), REACH, EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE), REACH: 2020-01-16 |
| UK regulation compliance | UKCA Mark |
| APAC compliance | China RoHS II (GB/T 26572-2011) |
| Sustainability | Product Lens™, Environmental Product Declaration (EPD) Available |
| Patent information | This product has one or more applicable patents. More information on patents can be found at https://www.belden.com/patents . |
| Priced Per | FT |
Images are for reference only. Specifications may change without notice — verify suitability for your application before purchase. The manufacturer's documentation controls.
