Belden 10GXS33009A1000, Copper Cable Cat6A 4PR 23 AWG Plenum White
SKU:Belden 10GXS33009A1000
● In stock
× 1,000 ft = Total: 1,000 ft
Description
Belden 10GXS33009A1000 is a 10GXS Category 6A Enhanced Premise Horizontal Cable (625MHz) for high-performance Ethernet up to 10GBASE-T in indoor plenum spaces. It features 4 bonded-pairs of 23 AWG solid bare copper conductors in a U/UTP construction. The cable uses FEP insulation and a Plenum-CMP Flamarrest® PVC-LS jacket, and includes a patented EquiSpline® center member with EquiBlock™ Barrier Technology. It supports modern network needs including Wi-Fi 6, PoE++, and data center EoR and MoR deployments.
Belden 10GXS33009A1000 Key Features
- 10GXS Category 6A Enhanced Premise Horizontal Cable (625MHz) for Ethernet up to 10GBASE-T.
- U/UTP construction with 4 bonded-pairs of 23 AWG solid bare copper conductors.
- FEP - Fluorinated Ethylene Propylene insulation with color code: White & Blue, White & Orange, White & Green, White & Brown.
- Plenum-CMP Flamarrest® PVC-LS jacket in White, with a patented EquiSpline® center member and EquiBlock™ Barrier Technology.
- Environmental suitability: Plenum, Indoor.
Belden 10GXS33009A1000 Applications
- Designed for premise horizontal cable installations where consistent, high-performance network cabling is required.
- Enables Ethernet up to 10GBASE-T for high-speed network links.
- Works for Wi-Fi 6 and Wi-Fi 5 network deployments.
- Supports PoE, PoE+, and PoE++ to help deliver power and data over the same cabling.
- Intended for use in noisy environments where robust performance is needed.
- Fits data center EoR and MoR deployments.
- Serves network backbone connections.
- Supports HDBaseT and HDBaseT 4K UHD applications.
Belden™ and all associated trademarks are the property of their respective owners.
Specifications
| Attribute | Value |
|---|---|
| Data category | Category 6A |
| Cable type | Data |
| Frequency rating | 625MHz |
| Conductor size | 23 AWG |
| Conductor stranding | Solid |
| Conductor Material | BC - Bare Copper |
| Number of pairs | 4 |
| Insulation Material | FEP - Fluorinated Ethylene Propylene |
| Jacket type | Plenum-CMP |
| Jacket Material | PVC - Polyvinyl Chloride |
| Material trade name | Flamarrest® |
| Jacket Color | White |
| Separator | Center Member (Patented EquiSpline®), EquiBlock™ Barrier Technology |
| Ripcord | Yes |
| Overall cable diameter (nominal) | 0.273 in (6.93 mm) |
| Bulk cable weight | 38 lbs/1000ft |
| Max. Conductor DCR | 75 Ohm/km (23 Ohm/1000ft) |
| Max. capacitance unbalance | 90 pF/100m |
| Delay (100 MHz) max. | 537.6 ns/100m |
| Delay skew (100 MHz) max. | 45 ns/100m |
| Nom. velocity of prop. | 69% |
| UL Voltage Rating | 300 V (CMP), 300 V (CL3P) |
| Max Pull Tension | 40 lbs (18 kg) |
| Bend radius (stationary min.) | 0.5 in (13 mm) |
| Bend radius (installation min.) | 2.5 in (64 mm) |
| UL temperature | 105°C |
| Operating | -20°C To +75°C |
| Installation | 0°C To +50°C |
| Storage | -20°C To +75°C |
| Flammability / reaction to fire | NFPA 262, UL 910 (Plenum), FT6 |
| NEC / UL compliance | Article 800, CMP, CMP-LP (0.7A), CL3P-LP (0.7A) |
| CEC / C(UL) compliance | CMP |
| CPR compliance | CPR Euroclass: Eca |
| ICEA compliance | S-116-732 |
| IEEE compliance | IEEE 802.3bt Type 1, Type 2, Type 3, Type 4 |
| NEMA Compliance | ANSI/NEMA WC-66 |
| TIA/EIA compliance | ANSI/TIA-568.2-D Category 6A |
| ISO/IEC compliance | ISO/IEC 11801-1, IEC 61156-5 |
| CENELEC compliance | Segregation class according EN50174-2 = a |
| European directive compliance | EU CE Mark, EU Directive 2015/863/EU (RoHS 2 amendment), REACH, EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE), REACH: 2020-01-16 |
| UK regulation compliance | UKCA Mark |
| APAC compliance | China RoHS II (GB/T 26572-2011) |
| Sustainability | Product Lens™, Environmental Product Declaration (EPD) Available |
| Non-Plenum number | 10GXS12 (Nonbonded)/10GXS32 |
| Patent information | This product has one or more applicable patents. More information on patents can be found at https://www.belden.com/patents . |
| Priced Per | FT |
Images are for reference only. Specifications may change without notice — verify suitability for your application before purchase. The manufacturer's documentation controls.
