Belden 10GXW13 003, CAT6A 4PR #23 U UTP CMP ORG, Orange Jacket
SKU:Belden 10GXW13 003
● In stock
× 1,000 ft = Total: 1,000 ft
Description
Belden 10GXW13 003 is a Category 6A premise horizontal cable for high-performance networks up to 500MHz in plenum, indoor spaces. It features a U/UTP construction with 4 pair of 23 AWG solid bare copper conductors and supports Ethernet 10GBASE-T, Wi-Fi 6, and PoE++, PoE+, and PoE. This cable uses FEP insulation and a Flamarrest® PVC-LS jacket, and includes a patented X-Spline® center member with EquiBlock™ Barrier Technology. The orange jacket is designed to meet NFPA 262 and UL 910 (Plenum) requirements.
Belden 10GXW13 003 Key Features
- Category 6A premise horizontal cable rated up to 500MHz for high-performance network cabling.
- U/UTP construction with 4 pair of 23 AWG solid bare copper conductors.
- FEP - Fluorinated Ethylene Propylene insulation with color code: White & Blue, White & Orange, White & Green, White & Brown.
- Flamarrest® PVC-LS jacket in orange with a center member (patented X-Spline®) and EquiBlock™ Barrier Technology.
- Plenum-CMP fire rating with NFPA 262 and UL 910 (Plenum) listed in flammability / reaction to fire.
Belden 10GXW13 003 Applications
- Designed for premise horizontal cable installations in plenum, indoor building spaces.
- Supports Ethernet 10GBASE-T network links where high-performance connectivity is required.
- Suitable for Wi-Fi 6 and Wi-Fi 5 infrastructure connections in building networks.
- Used for In-Building Wireless and In-Building Small Cells deployments.
- Applicable for Mobile RAN connectivity within supported network builds.
- Supports PoE++, PoE+, and PoE for delivering power over Ethernet where specified.
- Used in HDBaseT installations where listed as an application.
Belden™ and all associated trademarks are the property of their respective owners.
Specifications
| Attribute | Value |
|---|---|
| Type | Data |
| Overall cable diameter (nominal) | 0.250 in (6.35 mm) |
| Bulk cable weight | 34 lbs/1000ft (51 kg/km) |
| UL Voltage Rating | 300 V (CMP) |
| Max. Conductor DCR | 82 Ohm/km (25 Ohm/1000ft) |
| Max. capacitance unbalance | 45 pF/100m |
| Max. delay | 537.6 ns/100m |
| Max. delay skew | 45 ns/100m |
| Nom. velocity of prop. | 69% |
| Ripcord | Yes |
| UL temperature | 105°C |
| Operating temperature | -20°C To +75°C |
| Installation temperature | 0°C To +50°C |
| Storage temperature | -20°C To +75°C |
| Stationary min. bend radius | 1 in (25 mm) |
| Max Pull Tension | 25 lbs (11 kg) |
| NEC / UL compliance | Article 800, CMP, CMP-LP (0.5A), CL3P-LP (0.5A) |
| CEC / C(UL) compliance | CMP |
| ICEA compliance | S-116-732 |
| IEEE compliance | IEEE 802.3bt Type 1, Type 2, Type 3, Type 4 |
| NEMA Compliance | ANSI/NEMA WC-66 |
| TIA/EIA compliance | ANSI/TIA-568.2-D Category 6A |
| ISO/IEC compliance | ISO/IEC 11801-1, IEC 61156-5 |
| European directive compliance | EU CE Mark, EU Directive 2015/863/EU (RoHS 2 amendment), REACH, EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE), REACH: 2020-01-16 |
| APAC compliance | China RoHS II (GB/T 26572-2011) |
| Patent information | This product has one or more applicable patents. More information on patents can be found at https://www.belden.com/patents . |
| Priced Per | FT |
