Belden 10GXW13 004, CAT6A 4PR #23 U/UTP CMP YEL, Yellow Jacket
SKU:Belden 10GXW13 004
● In stock
× 1,000 ft = Total: 1,000 ft
Description
Belden 10GXW13 004 is a Category 6A premise horizontal cable for high-performance networks up to 500MHz. It features 4 pair of 23 AWG solid bare copper conductors in a U/UTP construction with a Flamarrest® PVC-LS jacket. This plenum-rated CMP cable is designed for indoor plenum installations and includes a patented X-Spline® center member with EquiBlock™ Barrier Technology to help maintain consistent performance in high-density pathways.
Belden 10GXW13 004 Key Features
- This Category 6A premise horizontal cable supports high-performance networks up to 500MHz.
- It uses 4 pair of 23 AWG solid bare copper conductors in a U/UTP construction.
- The plenum-rated CMP design is intended for indoor plenum installations.
- It features a Flamarrest® PVC-LS jacket.
- A patented X-Spline® center member with EquiBlock™ Barrier Technology helps maintain consistent performance in high-density pathways.
Belden 10GXW13 004 Applications
- This cable is intended for premise horizontal cable runs within a building.
- It supports Ethernet 10GBASE-T network links.
- For wireless connectivity deployments, it is suitable for Wi-Fi 6 and Wi-Fi 5.
- It can be used for in-building wireless systems.
- In-building small cells installations are supported.
- Mobile RAN connectivity is supported.
- PoE++, PoE+, and PoE power delivery over the network connection are supported.
- HDBaseT connectivity is supported.
Belden™ and all associated trademarks are the property of their respective owners.
Specifications
| Attribute | Value |
|---|---|
| Data category | Category 6A |
| Construction type | U/UTP |
| Number of pairs | 4 |
| Conductor size | 23 AWG |
| Conductor stranding | Solid |
| Conductor Material | BC - Bare Copper |
| Insulation Material | FEP - Fluorinated Ethylene Propylene |
| Pair color code | White & Blue, White & Orange, White & Green, White & Brown |
| Separator | Center Member (Patented X-Spline®), EquiBlock™ Barrier Technology |
| Jacket Material | PVC - Polyvinyl Chloride |
| Jacket trade name | Flamarrest® |
| Jacket Color | Yellow |
| Ripcord | Yes |
| Overall cable diameter (nominal) | 0.250 in (6.35 mm) |
| Bulk cable weight | 34 lbs/1000ft (51 kg/km) |
| Max. Conductor DCR | 82 Ohm/km (25 Ohm/1000ft) |
| Max. capacitance unbalance | 45 pF/100m |
| Max. delay | 537.6 ns/100m |
| Max. delay skew | 45 ns/100m |
| Nom. velocity of prop. | 69% |
| UL Voltage Rating | 300 V (CMP) |
| UL temperature | 105°C |
| Operating temperature | -20°C To +75°C |
| Installation temperature | 0°C To +50°C |
| Storage temperature | -20°C To +75°C |
| Stationary min. bend radius | 1 in (25 mm) |
| Max Pull Tension | 25 lbs (11 kg) |
| Environmental suitability | Plenum, Indoor |
| Fire rating | Plenum-CMP |
| Flammability / reaction to fire | NFPA 262, UL 910 (Plenum), FT6 |
| NEC / UL compliance | Article 800, CMP, CMP-LP (0.5A), CL3P-LP (0.5A) |
| CEC / C(UL) compliance | CMP |
| ICEA compliance | S-116-732 |
| IEEE compliance | IEEE 802.3bt Type 1, Type 2, Type 3, Type 4 |
| NEMA Compliance | ANSI/NEMA WC-66 |
| TIA/EIA compliance | ANSI/TIA-568.2-D Category 6A |
| ISO/IEC compliance | ISO/IEC 11801-1, IEC 61156-5 |
| European directive compliance | EU CE Mark, EU Directive 2015/863/EU (RoHS 2 amendment), REACH, EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE), REACH: 2020-01-16 |
| APAC compliance | China RoHS II (GB/T 26572-2011) |
| Patent info | This product has one or more applicable patents. More information on patents can be found at https://www.belden.com/patents . |
| Priced Per | FT |
Images are for reference only. Specifications may change without notice — verify suitability for your application before purchase. The manufacturer's documentation controls.
