Belden 10GXW13 008, CAT6A 4PR #23 U/UTP CMP GRY, Gray Jacket

Belden 10GXW13 008 is a Category 6A premise horizontal data cable built with 4 pairs of 23 AWG solid bare copper conductors in a U/UTP construction. It is designed for high-performance Ethernet up to 500MHz and supports Ethernet 10GBASE-T, along with PoE++, PoE+, and PoE. This plenum-rated Plenum-CMP cable features a Flamarrest® PVC-LS jacket in gray and includes a patented X-Spline® center member with EquiBlock™ Barrier Technology. The nominal overall cable diameter is 0.250 in (6.35 mm).

Belden 10GXW13 008 Key Features

• Category 6A premise horizontal cable for in-building data installations.
• 4 pairs of 23 AWG solid bare copper conductors in a U/UTP construction.
• 500MHz bandwidth for high-performance Ethernet networks.
• Supports Ethernet 10GBASE-T and power delivery options including PoE++, PoE+, and PoE.
• Plenum-CMP rating for plenum, indoor environments.
• Flamarrest® PVC-LS jacket in gray.
• Patented X-Spline® center member with EquiBlock™ Barrier Technology.
• 0.250 in (6.35 mm) nominal overall cable diameter.

Belden 10GXW13 008 Applications

• Use it for premise horizontal cabling where consistent in-building data performance is required.
• Support Ethernet 10GBASE-T network links in high-performance Ethernet deployments.
• Connect Wi-Fi 6 and Wi-Fi 5 infrastructure within a building.
• Deploy it for in-building wireless installations, including in-building small cells.
• Use it for Mobile RAN connectivity within supported network architectures.
• Power network devices using PoE++, PoE+, and PoE.
• Use it in HDBaseT installations where supported by the system design.
