Belden 10GXW13 009, 23 4P UTP CMP Solid BC CAT6A WHITE
SKU:Belden 10GXW13 009
● In stock
× 1,000 ft = Total: 1,000 ft
Description
Belden 10GXW13 009 is a Category 6A premise horizontal cable for Ethernet 10GBASE-T networks up to 500MHz. It is built with 4 pair of 23 AWG solid bare copper conductors in a U/UTP - unshielded twisted pair construction. This CMP plenum cable features a Flamarrest® PVC-LS jacket, a patented X-Spline® center member, and EquiBlock™ Barrier Technology. It has a 0.250 in (6.35 mm) overall cable diameter (nominal) and a white jacket.
Belden 10GXW13 009 Key Features
- Category 6A data cable designed for Ethernet 10GBASE-T networks up to 500MHz.
- U/UTP - unshielded twisted pair construction with 4 pair of 23 AWG solid bare copper conductors.
- CMP plenum rating with environmental suitability listed as plenum, indoor.
- Flamarrest® PVC-LS jacket in white.
- Patented X-Spline® center member with EquiBlock™ Barrier Technology.
- 0.250 in (6.35 mm) overall cable diameter (nominal).
Belden 10GXW13 009 Applications
- Use it for premise horizontal cable runs in structured cabling installations.
- Support Ethernet 10GBASE-T links where up to 500MHz bandwidth is required.
- Deploy it for Wi-Fi 6 and Wi-Fi 5 connectivity within a building.
- Install it in in-building wireless and in-building small cells applications.
- Apply it for mobile RAN connectivity inside facilities.
- Support PoE, PoE+, and PoE++ powered network connections.
- Use it with HDBaseT systems where Category 6A cabling is specified.
Belden™ and all associated trademarks are the property of their respective owners.
Specifications
| Attribute | Value |
|---|---|
| Type | Data |
| Insulation Material | FEP - Fluorinated Ethylene Propylene |
| Color Code | White & Blue, White & Orange, White & Green, White & Brown |
| Ripcord | Yes |
| UL Voltage Rating | 300 V (CMP) |
| Bulk cable weight | 34 lbs/1000ft (51 kg/km) |
| Max. Conductor DCR | 82 Ohm/km (25 Ohm/1000ft) |
| Max. capacitance unbalance | 45 pF/100m |
| Max. delay | 537.6 ns/100m |
| Max. delay skew | 45 ns/100m |
| Nom. velocity of prop. | 69% |
| Stationary min. bend radius | 1 in (25 mm) |
| Max Pull Tension | 25 lbs (11 kg) |
| UL temperature | 105°C |
| Operating temperature | -20°C To +75°C |
| Installation temperature | 0°C To +50°C |
| Storage temperature | -20°C To +75°C |
| Fire rating | Plenum |
| Flammability / reaction to fire | NFPA 262, UL 910 (Plenum), FT6 |
| NEC / UL compliance | Article 800, CMP, CMP-LP (0.5A), CL3P-LP (0.5A) |
| CEC / C(UL) compliance | CMP |
| ICEA compliance | S-116-732 |
| IEEE compliance | IEEE 802.3bt Type 1, Type 2, Type 3, Type 4 |
| NEMA Compliance | ANSI/NEMA WC-66 |
| TIA/EIA compliance | ANSI/TIA-568.2-D Category 6A |
| ISO/IEC compliance | ISO/IEC 11801-1, IEC 61156-5 |
| European directive compliance | EU CE Mark, EU Directive 2015/863/EU (RoHS 2 amendment), REACH, EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE), REACH: 2020-01-16 |
| APAC compliance | China RoHS II (GB/T 26572-2011) |
| Patent information | This product has one or more applicable patents. More information on patents can be found at https://www.belden.com/patents . |
| Priced Per | FT |
Images are for reference only. Specifications may change without notice — verify suitability for your application before purchase. The manufacturer's documentation controls.
