Belden 1213 009U, Enhanced Category 5E 4 pair U UTP CMP White
SKU:Belden 1213 009U
● In stock
× 1,000 ft = Total: 1,000 ft
Description
Belden 1213 009U is an Enhanced Category 5E+ premise horizontal cable (350MHz) for Ethernet networks and PoE delivery. It features 4 pair of 24 AWG solid bare copper conductors in a U/UTP design. For plenum indoor pathways, it uses a Plenum-CMP Flamarrest® PVC-LS jacket and includes a ripcord for easier pulls and stripping. It meets ANSI/TIA-568.2-D Category 5e and NFPA 262 / UL 910 (Plenum).
Belden 1213 009U Key Features
- Enhanced Category 5E+ premise horizontal cable (350MHz) for structured cabling installations.
- 4 pair of 24 AWG solid bare copper conductors in a U/UTP design.
- Plenum-CMP Flamarrest® PVC-LS jacket for plenum indoor pathways.
- Includes a ripcord to support easier pulls and stripping during installation.
- Meets ANSI/TIA-568.2-D Category 5e and NFPA 262 / UL 910 (Plenum).
Belden 1213 009U Applications
- Use it as a premise horizontal cable for structured cabling runs within a building.
- Support Ethernet 1000BASE-T links in network installations.
- Deploy it for Ethernet 100BASE-TX connectivity.
- Apply it to Ethernet 10BASE-T connections where applicable.
- Deliver PoE++, PoE+, and PoE over the network cabling.
Belden™ and all associated trademarks are the property of their respective owners.
Specifications
| Attribute | Value |
|---|---|
| Data category | Category 5e |
| Pairs | 4 |
| Conductor size | 24 AWG |
| Conductor stranding | Solid |
| Conductor Material | BC - Bare Copper |
| Shield Type | U/UTP |
| Insulation Material | PO+FEP - Polyolefin + Fluorinated Ethylene Propylene |
| Color Code | White/Blue Stripe & Blue, White/Orange Stripe & Orange, White/Green Stripe & Green, White/Brown Stripe & Brown |
| Jacket Material | PVC - Polyvinyl Chloride |
| Jacket trade name | Flamarrest® |
| Jacket Color | White |
| Overall cable diameter (nominal) | 0.207 in (5.26 mm) |
| Max. Conductor DCR | 89 Ohm/km (27 Ohm/1000ft) |
| Max. capacitance unbalance | 330 pF/100m |
| Delay (100 MHz) max. | 537.6 ns/100m |
| Delay skew (100 MHz) max. | 25 ns/100m |
| Nom. velocity of prop. | 72% |
| UL Voltage Rating | 300 V (CMP) |
| Priced Per | FT |
Images are for reference only. Specifications may change without notice — verify suitability for your application before purchase. The manufacturer's documentation controls.
