Belden 1592A 004, Category 5e Patch Cable UTP CM Yellow
SKU:Belden 1592A 004
● In stock
× 1,000 ft = Total: 1,000 ft
Description
Belden 1592A 004 is a Category 5e premise patch cable (200MHz) for Ethernet connectivity. It features a U/UTP design with 4 pair 24 AWG stranded (7x32) BC - Bare Copper conductors, PO - Polyolefin insulation, and a PVC - Polyvinyl Chloride jacket. This CM (Article 800, CM) indoor (Not Riser or Plenum) cable is rated 300 V (CM) and meets UL 1685 (UL Loading-Limited Smoke). The Yellow jacket helps with identification in structured cabling and patching environments.
Belden 1592A 004 Key Features
- Category 5e premise patch cable (200MHz) for Ethernet connectivity.
- U/UTP construction with 4 pair 24 AWG stranded (7x32) BC - Bare Copper conductors.
- PO - Polyolefin insulation with a PVC - Polyvinyl Chloride jacket in Yellow for identification.
- CM (Article 800, CM) indoor (Not Riser or Plenum) rating with UL 1685 (UL Loading-Limited Smoke).
- UL voltage rating: 300 V (CM).
Belden 1592A 004 Applications
- Use in premise patch cable installations where consistent Ethernet connectivity is required.
- Enable Ethernet 10BASE-T connections in structured cabling and patching environments.
- Support Ethernet 100BASE-TX links for network equipment interconnects.
- Handle Ethernet 1000BASE-T for higher-speed network patching needs.
- Fit PoE, PoE+, and PoE++ deployments where power and data are carried over the same Ethernet link.
Belden™ and all associated trademarks are the property of their respective owners.
Specifications
| Attribute | Value |
|---|---|
| Type | Data |
| Number of pairs | 4 |
| Pair construction | Twisted pairs |
| Conductor size | 24 AWG |
| Conductor Type | Stranded |
| Stranding | 7x32 |
| Conductor Material | BC - Bare Copper |
| Insulation Material | PO - Polyolefin |
| Color Code | White/Blue Stripe & Blue, White/Orange Stripe & Orange, White/Green Stripe & Green, White/Brown Stripe & Brown |
| Jacket Material | PVC - Polyvinyl Chloride |
| Jacket Color | Yellow |
| Ripcord | No |
| Overall cable diameter (nominal) | 0.213 in (5.41 mm) |
| Bulk cable weight | 22 lbs/1000ft |
| Max. Conductor DCR | 93.8 Ohm/km (28.6 Ohm/1000ft) |
| Max. capacitance unbalance | 330 pF/100m |
| Nom. velocity of prop. | 69% |
| Delay (100 MHz) max. | 537.6 ns/100m |
| Delay skew (100 MHz) max. | 45 ns/100m |
| Typical delay skew (100 MHz) | 37 ns/100m |
| Environmental suitability | Indoor (Not Riser or Plenum), Indoor |
| UL temperature | 75°C |
| Operating temperature | -20°C To +75°C |
| Installation temperature | 0°C To +50°C |
| Storage temperature | -20°C To +75°C |
| Bend radius (stationary min.) | 1.0 in (25 mm) |
| Bend radius (installation min.) | 2.25 in (57.2 mm) |
| Max Pull Tension | 25 lbs (11 kg) |
| TIA/EIA compliance | ANSI/TIA-568.2-D Category 5e |
| ISO/IEC compliance | ISO/IEC 11801-1, IEC 61156-6 |
| IEEE compliance | IEEE 802.3bt Type 1, Type 2, Type 3 |
| ICEA compliance | S-90-661 |
| NEMA Compliance | NEMA WC-63.1 |
| CEC / C(UL) compliance | CM |
| Third party performance verification | Category 5e Patch |
| European directive compliance | EU CE Mark, EU Directive 2015/863/EU (RoHS 2 amendment), REACH, EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE), REACH: 2020-01-16 |
| APAC compliance | China RoHS II (GB/T 26572-2011) |
| Sustainability | Product Lens™, Environmental Product Declaration (EPD) Available |
| Priced Per | FT |
Images are for reference only. Specifications may change without notice — verify suitability for your application before purchase. The manufacturer's documentation controls.
