Belden 1592A 006U, Category 5e Patch Cable UTP CM Light Blue
SKU:Belden 1592A 006U
$600.00
● In stock
× 1,000 ft = Total: 1,000 ft
Description
Belden 1592A 006U is a Category 5e Premise Patch Cable (200MHz) designed for Ethernet connectivity and PoE delivery in indoor environments. It features 4 pair 24 AWG stranded (7x32) BC - Bare Copper conductors in a U/UTP construction, with PO - Polyolefin insulation and a PVC - Polyvinyl Chloride jacket. The cable has a Blue jacket color and is rated 300 V (CM) with a UL temperature of 75°C. It supports performance specifications through 200 MHz and is listed to multiple industry standards including ANSI/TIA-568.2-D Category 5e and ISO/IEC 11801-1.
Belden 1592A 006U Key Features
- Category 5e Premise Patch Cable (200MHz) construction for structured cabling patching needs.
- 4 pair 24 AWG stranded (7x32) BC - Bare Copper conductors in a U/UTP design.
- PO - Polyolefin insulation with a PVC - Polyvinyl Chloride jacket.
- Blue jacket color for easy identification in patching and cable management.
- UL Voltage Rating: 300 V (CM) and UL temperature: 75°C.
- Environmental suitability: Indoor (Not Riser or Plenum).
- RJ45 compatible.
Mechanical Ratings
Belden™ and all associated trademarks are the property of their respective owners.
Specifications
| Attribute | Value |
|---|---|
| Data category | Category 5e |
| Cable type | Category 5e Premise Patch Cable (200MHz) |
| Pair count | 4 Pair |
| Shielding | U/UTP |
| Conductor size | 24 AWG |
| Conductor stranding | 7x32 |
| Conductor Material | BC - Bare Copper |
| Insulation Material | PO - Polyolefin |
| Color Code | White/Blue Stripe & Blue, White/Orange Stripe & Orange, White/Green Stripe & Green, White/Brown Stripe & Brown |
| Jacket Material | PVC - Polyvinyl Chloride |
| Jacket Color | Blue |
| Overall cable diameter (nominal) | 0.213 in (5.41 mm) |
| Ripcord | No |
| Max. Conductor DCR | 93.8 Ohm/km (28.6 Ohm/1000ft) |
| Max. capacitance unbalance | 330 pF/100m |
| Nom. velocity of prop. | 69% |
| Delay (100 MHz) max. | 537.6 ns/100m |
| Delay skew (100 MHz) max. | 45 ns/100m |
| Typical delay skew (100 MHz) | 37 ns/100m |
| 1 MHz performance | Max. Insertion Loss (Attenuation) 2.4 dB/100m; Min. NEXT 65.3; Min. PSNEXT 62.3; Min. ACRF (ELFEXT) 63.8; Min. PSACRF (PSELFEXT) 60.8; Min. RL (Return Loss) 20.0; Max./Min. Input Impedance (unFitted) 100 ± 15; Max./Min. Fitted Impedance 100 ± 15 |
| 4 MHz performance | Max. Insertion Loss (Attenuation) 4.9 dB/100m; Min. NEXT 56.3; Min. PSNEXT 53.3; Min. ACRF (ELFEXT) 51.7; Min. PSACRF (PSELFEXT) 48.7; Min. RL (Return Loss) 23.0; Max./Min. Input Impedance (unFitted) 100 ± 15; Max./Min. Fitted Impedance 100 ± 15 |
| 8 MHz performance | Max. Insertion Loss (Attenuation) 6.9 dB/100m; Min. NEXT 51.8; Min. PSNEXT 48.8; Min. ACRF (ELFEXT) 45.7; Min. PSACRF (PSELFEXT) 42.7; Min. RL (Return Loss) 24.5; Max./Min. Input Impedance (unFitted) 100 ± 15; Max./Min. Fitted Impedance 100 ± 15 |
| 10 MHz performance | Max. Insertion Loss (Attenuation) 7.8 dB/100m; Min. NEXT 50.3; Min. PSNEXT 47.3; Min. ACRF (ELFEXT) 43.8; Min. PSACRF (PSELFEXT) 40.8; Min. RL (Return Loss) 25.0; Max./Min. Input Impedance (unFitted) 100 ± 15; Max./Min. Fitted Impedance 100 ± 15 |
| 16 MHz performance | Max. Insertion Loss (Attenuation) 9.9 dB/100m; Min. NEXT 47.3; Min. PSNEXT 44.2; Min. ACRF (ELFEXT) 39.7; Min. PSACRF (PSELFEXT) 36.7; Min. RL (Return Loss) 25.0; Max./Min. Input Impedance (unFitted) 100 ± 15; Max./Min. Fitted Impedance 100 ± 15 |
| 20 MHz performance | Max. Insertion Loss (Attenuation) 11.1 dB/100m; Min. NEXT 45.8; Min. PSNEXT 42.8; Min. ACRF (ELFEXT) 37.7; Min. PSACRF (PSELFEXT) 34.7; Min. RL (Return Loss) 25.0; Max./Min. Input Impedance (unFitted) 100 ± 15; Max./Min. Fitted Impedance 100 ± 15 |
| 25 MHz performance | Max. Insertion Loss (Attenuation) 12.5 dB/100m; Min. NEXT 44.3; Min. PSNEXT 41.3; Min. ACRF (ELFEXT) 35.8; Min. PSACRF (PSELFEXT) 32.8; Min. RL (Return Loss) 24.3; Max./Min. Input Impedance (unFitted) 100 ± 15; Max./Min. Fitted Impedance 100 ± 15 |
| 31.25 MHz performance | Max. Insertion Loss (Attenuation) 14.1 dB/100m; Min. NEXT 42.9; Min. PSNEXT 39.9; Min. ACRF (ELFEXT) 33.9; Min. PSACRF (PSELFEXT) 30.9; Min. RL (Return Loss) 23.6; Max./Min. Input Impedance (unFitted) 100 ± 15; Max./Min. Fitted Impedance 100 ± 15 |
| 62.5 MHz performance | Max. Insertion Loss (Attenuation) 20.4 dB/100m; Min. NEXT 38.4; Min. PSNEXT 35.4; Min. ACRF (ELFEXT) 27.8; Min. PSACRF (PSELFEXT) 24.8; Min. RL (Return Loss) 21.5; Max./Min. Input Impedance (unFitted) 100 ± 15; Max./Min. Fitted Impedance 100 ± 15 |
| 100 MHz performance | Max. Insertion Loss (Attenuation) 26.4 dB/100m; Min. NEXT 35.3; Min. PSNEXT 32.3; Min. ACRF (ELFEXT) 23.8; Min. PSACRF (PSELFEXT) 20.8; Min. RL (Return Loss) 20.1; Max./Min. Input Impedance (unFitted) 100 ± 15; Max./Min. Fitted Impedance 100 ± 15 |
| 155 MHz performance | Max. Insertion Loss (Attenuation) 33.7 dB/100m; Min. NEXT 32.5; Min. PSNEXT 29.4; Min. ACRF (ELFEXT) 19.9; Min. PSACRF (PSELFEXT) 16.9; Min. RL (Return Loss) 15.8; Max./Min. Input Impedance (unFitted) 100 ± 25; Max./Min. Fitted Impedance 100 ± 15 |
| 200 MHz performance | Max. Insertion Loss (Attenuation) 38.9 dB/100m; Min. NEXT 30.8; Min. PSNEXT 27.8; Min. ACRF (ELFEXT) 17.7; Min. PSACRF (PSELFEXT) 14.7; Min. RL (Return Loss) 15.0; Max./Min. Input Impedance (unFitted) 100 ± 25; Max./Min. Fitted Impedance 100 ± 15 |
| Operating temperature | -20°C To +75°C |
| Installation temperature | 0°C To +50°C |
| Storage temperature | -20°C To +75°C |
| Bend radius (stationary min.) | 1.0 in ( |
| Priced Per | FT |
Images are for reference only. Specifications may change without notice — verify suitability for your application before purchase. The manufacturer's documentation controls.
