Belden 1752A 010, Enhanced Cat5e Patch Cable UTP CM Black
Description
Belden 1752A 010 is a Category 5e+ premise patch cable rated to 350MHz, built with 4 bonded pairs of 24 AWG stranded (7x32) TC - Tinned Copper conductors. It is a U/UTP (Unshielded) CM cable with a PVC - Polyvinyl Chloride jacket in black and PO - Polyolefin insulation. Designed for indoor use, it meets ANSI/TIA-568.2-D Category 5e and ISO/IEC 11801-1.
Belden 1752A 010 Key Features
- This is a Category 5e+ premise patch cable rated to 350MHz.
- It features U/UTP (Unshielded) construction with 4 bonded pairs.
- It uses 24 AWG stranded (7x32) TC - Tinned Copper conductors.
- It has a PVC - Polyvinyl Chloride jacket in black with PO - Polyolefin insulation.
- It is designed for indoor use with NEC / UL compliance: Article 800, CM.
Belden 1752A 010 Applications
- Use it for premise patch cable installations where Category 5e Patch performance is required.
- Support Ethernet 10BASE-T connectivity in indoor premise environments.
- Enable Ethernet 100BASE-TX links for network connections.
- Run Ethernet 1000BASE-T applications for higher-speed Ethernet networks.
- Deploy it for PoE, PoE+, and PoE++.
Patent Information
- This product has one or more applicable patents. More information on patents can be found at https://www.belden.com/patents.
Belden™ and all associated trademarks are the property of their respective owners.
Specifications
| Attribute | Value |
|---|---|
| Data category | Category 5e |
| Number of pairs | 4 |
| Bonded-pair | Yes |
| Conductor size | 24 AWG |
| Conductor stranding | 7x32 |
| Conductor Material | TC - Tinned Copper |
| Conductor Type | Stranded |
| Insulation Material | PO - Polyolefin |
| Color Code | White/Blue Stripe & Blue, White/Orange Stripe & Orange, White/Green Stripe & Green, White/Brown Stripe & Brown |
| Jacket Material | PVC - Polyvinyl Chloride |
| Jacket Color | Black |
| Ripcord | No |
| Overall cable diameter (nominal) | 0.220 in (5.59 mm) |
| Bulk cable weight | 21 lbs/1000ft |
| UL Voltage Rating | 300 V (CM) |
| Max. Conductor DCR | 90 Ohm/km (27 Ohm/1000ft) |
| Max. capacitance unbalance | 160 pF/100m |
| Delay (100 MHz) | 537.6 ns/100m |
| Delay skew (100 MHz) | 25 ns/100m |
| Nom. velocity of prop. (100 MHz) | 70% |
| Third party performance verification | Category 5e Patch |
| UL temperature | 75°C |
| Operating temperature | -20°C To +75°C |
| Installation temperature | 0°C To +50°C |
| Storage temperature | -20°C To +75°C |
| Bend radius (stationary min.) | 1.0 in (25 mm) |
| Bend radius (installation min.) | 2.2 in (56 mm) |
| Max Pull Tension | 40 lbs (18 kg) |
| Environmental suitability | Indoor |
| CEC / C(UL) compliance | CM |
| Flammability / reaction to fire | UL 1685 (UL 1581) Vertical Tray, FT1 |
| ICEA compliance | S-90-661 |
| TIA/EIA compliance | ANSI/TIA-568.2-D Category 5e |
| ISO/IEC compliance | ISO/IEC 11801-1, IEC 61156-6 |
| IEEE compliance | IEEE 802.3bt Type 1, Type 2, Type 3 |
| NEMA Compliance | NEMA WC-63.1 |
| European directive compliance | EU CE Mark, EU Directive 2015/863/EU (RoHS 2 amendment), REACH, EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE), REACH: 2020-01-16 |
| APAC compliance | China RoHS II (GB/T 26572-2011) |
| Sustainability | Product Lens™, Environmental Product Declaration (EPD) Available |
| Priced Per | FT |
