Belden 19125 010, Portable Cordage Type SJ 3C 18 AWG EPDM Rubber, Black Jacket
SKU:Belden 19125 010
● In stock
Description
Belden 19125 010 is a Type SJ portable cordage with 3 stranded 18 AWG BC - Bare Copper conductors, EPDM - Ethylene Propylene Diene Monomer insulation, and an SBR - Styrene Butadiene Rubber outer jacket in black. This unshielded cord is rated 300 V and 60°C and includes a paper tape separator. It is designed for flexible handling with defined bend radius and max pull tension limits, and it supports indoor and outdoor environmental suitability.
Belden 19125 010 Applications
- Supports portable power connections in indoor and outdoor environments where a Type SJ cord is required.
- Meets installations that require compliance with Article 400, SJ and FT2 flammability.
- Provides flexible handling where bend radius and max pull tension limits must be followed during installation and use.
Belden™ and all associated trademarks are the property of their respective owners.
Specifications
| Attribute | Value |
|---|---|
| Product type | Cordage |
| UL type | SJ |
| Number of Conductors | 3 |
| Conductor size | 18 AWG |
| Conductor stranding | 42x34 |
| Conductor Material | BC - Bare Copper |
| Insulation Material | EPDM - Ethylene Propylene Diene Monomer |
| Nom. thickness (insulation) | 0.032 in (0.81 mm) |
| Nom. insulation diameter | 0.315 in mm |
| Color Code | Black, White, Green |
| Shielding | No Shield |
| Separator | Paper Tape |
| Outer jacket material | SBR - Styrene Butadiene Rubber |
| Nom. thickness (outer jacket) | 0.044 in (1.1 mm) |
| Overall cable diameter (nominal) | 0.328 in |
| Jacket Color | Black |
| UL Voltage Rating | 300 V |
| Nom. conductor DCR | 6.65 Ohm/1000ft |
| Max. current | 7 Amps per Conductor at 25ºC (over 50 ft) |
| UL temperature | 60°C |
| Operating temperature | -20°C To +60°C |
| Bend radius (stationary min.) | 3.28 in (83.3 mm) |
| Bend radius (installation min.) | 3.28 in |
| Max Pull Tension | 61.5 lbs (27.9 kg) |
| Bulk cable weight | 54 lbs/1000ft |
| Environmental suitability | Indoor, Outdoor |
| Flammability / reaction to fire | FT2 |
| NEC / UL compliance | Article 400, SJ |
| European directive compliance | EU CE Mark, EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE) |
| APAC compliance | China RoHS II (GB/T 26572-2011) |
| Other Part Numbers | 19125 010, 19125 010100, 19125 010250, 19125 010500, 19125 0101000, UPC 612825126652 |
| Priced Per | FT |
