Belden 19130 010, Portable Cordage Type SJ 3C 16 AWG EPDM Rubber, Black Jacket
SKU:Belden 19130 010
● In stock
Description
Belden 19130 010 is a portable cordage UL type SJ designed for flexible power and equipment connections where a tough rubber jacket is needed. It features 3 stranded 16 AWG bare copper conductors with EPDM insulation and a smooth SBR rubber outer jacket in black. This unshielded cord is rated 300 V and 60°C, includes a paper tape separator, and supports up to 19 Amps per Conductor at 25ºC (10 Amps over 50 ft).
Belden 19130 010 Applications
- Use it for flexible power and equipment connections where a tough rubber jacket is needed.
Belden™ and all associated trademarks are the property of their respective owners.
Specifications
| Attribute | Value |
|---|---|
| Product type | Cordage |
| UL type | SJ |
| Number of Conductors | 3 |
| Conductor size | 16 AWG |
| Conductor stranding | 26x30 |
| Conductor Material | BC - Bare Copper |
| Insulation Material | EPDM - Ethylene Propylene Diene Monomer |
| Color Code | Black, White, Green |
| Shielding | No Shield |
| Separator | Paper Tape |
| Jacket Material | SBR - Styrene Butadiene Rubber |
| Jacket Color | Black |
| Nom. thickness (insulation) | 0.031 in (0.79 mm) |
| Nom. insulation diameter | 0.123 in mm |
| Nom. thickness (jacket) | 0.044 in (1.1 mm) |
| Overall cable diameter (nominal) | 0.353 in |
| Bulk cable weight | 70 lbs/1000ft |
| UL Voltage Rating | 300 V |
| Nom. conductor DCR | 4.4 Ohm/1000ft |
| Max. current | 19 Amps per Conductor at 25ºC (10 Amps over 50 ft); 10 Amps per Conductor at 25ºC (over 50 ft) |
| UL temperature | 60°C |
| Operating temperature | -25°C to 60°C |
| Bend radius (stationary min.) | 3.53 in (89.7 mm) |
| Bend radius (installation min.) | 3.53 in |
| Max Pull Tension | 80 lbs (36 kg) |
| Flammability / reaction to fire | FT2 |
| NEC / UL compliance | Article 400, SJ |
| European directive compliance | EU CE Mark, EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE) |
| APAC compliance | China RoHS II (GB/T 26572-2011) |
| Other Part Numbers | 19130 010, 19130 010100, 19130 010250, 19130 010500, 19130 0101000, UPC 612825126683 |
| Priced Per | FT |
