Belden 19140 008, Portable Cordage SVT 2C 18 AWG PVC Jacket, Gray Jacket
SKU:Belden 19140 008
● In stock
Description
Belden 19140 008 is portable cordage built as UL Type SVT for flexible power and general-purpose cord applications. It features 2 stranded 18 AWG BC - Bare Copper conductors with PVC - Polyvinyl Chloride insulation and a PVC - Polyvinyl Chloride outer jacket in a gray finish. Electrical characteristics include a 300 V UL Voltage Rating, 60°C UL temperature, and a nominal Conductor DCR of 6.97 Ohm/1000ft. A paper tape separator and oil resistance support durability in demanding environments.
Belden 19140 008 Applications
- Use for flexible power and general-purpose cord applications where UL Type SVT portable cordage is required.
- Choose for installations that benefit from oil resistance in demanding environments.
Belden™ and all associated trademarks are the property of their respective owners.
Specifications
| Attribute | Value |
|---|---|
| Product type | Cordage |
| Cable type | Portable cordage |
| UL type | SVT |
| Number of Conductors | 2 |
| Conductor size | 18 AWG |
| Conductor Material | BC - Bare Copper |
| Stranding | 42x34 |
| Insulation Material | PVC - Polyvinyl Chloride |
| Separator | Paper Tape |
| Outer jacket material | PVC - Polyvinyl Chloride |
| Nom. thickness (insulation) | 0.018 in (0.46 mm) |
| Nom. insulation diameter | 0.084 in (2.1 mm) |
| Nom. thickness (outer jacket) | 0.036 in (0.91 mm) |
| Nom. diameter | 0.243 in |
| Bulk cable weight | 32 lbs/1000ft |
| UL Voltage Rating | 300 V |
| Nom. conductor DCR | 6.97 Ohm/1000ft |
| Max. current | 10 Amps per Conductor at 25ºC (7 Amps over 50 ft); 7 Amps per Conductor at 25ºC (over 50 ft) |
| UL temperature | 60°C |
| Max Pull Tension | 42.6 lbs (19.3 kg) |
| Environmental suitability | Oil Resistance |
| Color Code | Black, White |
| Jacket Color | Gray |
| NEC / UL compliance | Article 400, SVT |
| AWM compliance | SVT |
| Standards | UL/CSA |
| European directive compliance | EU CE Mark, EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE) |
| APAC compliance | China RoHS II (GB/T 26572-2011) |
| Priced Per | FT |
Images are for reference only. Specifications may change without notice — verify suitability for your application before purchase. The manufacturer's documentation controls.
