Belden 19205 010, Portable Cordage SO 3C 10 AWG EPDM Rubber Jacket, Black Jacket
SKU:Belden 19205 010
● In stock
Description
Belden 19205 010 is a UL type SO cordage with 3 stranded 10 AWG BC - Bare Copper conductors, EPDM - Ethylene Propylene Diene Monomer insulation, and a CPE - Chlorinated Polyethylene (Thermoset) outer jacket. It is rated 600 V and 90°C, with an operating temperature range of -20°C To +90°C. This portable cordage features a smooth black jacket, a Black, White, Green conductor color code, and is listed for indoor use with oil resistance.
Belden 19205 010 Applications
- Handles demanding power applications where flexibility and oil resistance are required.
- Works for indoor use in environments where oil resistance is needed.
- Meets installation needs that must comply with Article 400, SO requirements.
Belden™ and all associated trademarks are the property of their respective owners.
Specifications
| Attribute | Value |
|---|---|
| Product type | Cordage |
| UL type | SO |
| Conductor(s) | 3 |
| Conductor size | 10 AWG |
| Conductor stranding | 105x30 |
| Conductor Material | BC - Bare Copper |
| Insulation Material | EPDM - Ethylene Propylene Diene Monomer |
| Separator | Paper Tape |
| Shield | No Shield |
| Outer jacket material | CPE - Chlorinated Polyethylene (Thermoset) |
| Nom. insulation thickness | 0.05 in (1.3 mm) |
| Nom. insulation diameter | 0.224 in (5.69 mm) |
| Nom. jacket thickness | 0.099 in (2.5 mm) |
| Overall cable diameter (nominal) | 0.681 in |
| Bulk cable weight | 293 lbs/1000ft |
| UL Voltage Rating | 600 V |
| Nom. conductor DCR | 1.09 Ohm/1000ft |
| Max. current | 30 Amps per Conductor at 25ºC (25 Amps over 50 ft) |
| UL temperature | 90°C |
| Operating temperature | -20°C To +90°C |
| Stationary min. bend radius | 6.81 in (173 mm) |
| Installation min. bend radius | 6.81 in |
| Max Pull Tension | 409.5 lbs (185.7 kg) |
| Environmental suitability | Indoor, Oil Resistance |
| Color Code | Black, White, Green |
| Jacket Color | Black |
| NEC / UL compliance | Article 400, SO |
| AWM compliance | SO |
| CEC / C(UL) compliance | LL7874 |
| European directive compliance | EU CE Mark, EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE) |
| Priced Per | FT |
