Belden 19364 010, Portable Cordage Type SJT 3C 14 AWG PVC Jacket, Black Jacket
SKU:Belden 19364 010
● In stock
Description
Belden 19364 010 is UL Type SJT portable cordage for supplying power to appliances and tools, featuring a black PVC outer jacket. It is constructed with 3 stranded 14 AWG bare copper conductors with PVC insulation and an international color code of Light Blue, Brown, Green/Yellow. This cable includes a tape outer shield of Bi-Laminate (Alum+Poly) with 100% coverage plus a 20 AWG (7x28) TC drainwire. It is rated 300 V (Type SJT) and 60°C, with a max. current of 15 Amps per Conductor @ 30°C.
Belden 19364 010 Key Features
- UL Type SJT portable cordage designed for supplying power to appliances and tools.
- 3 stranded 14 AWG bare copper conductors with PVC insulation and color code: Light Blue, Brown, Green/Yellow.
- Tape outer shield made of Bi-Laminate (Alum+Poly) with 100% coverage and a 20 AWG (7x28) TC drainwire.
- Electrical ratings include 300 V (Type SJT), 60°C, and max. current of 15 Amps per Conductor @ 30°C.
- Black PVC outer jacket.
Belden 19364 010 Applications
- Use this portable cordage to supply power to appliances and tools.
Belden™ and all associated trademarks are the property of their respective owners.
Specifications
| Attribute | Value |
|---|---|
| Product type | SJT |
| Number of Conductors | 3 |
| Conductor size | 14 AWG |
| Stranding | 41x30 |
| Conductor Material | BC - Bare Copper |
| Notes | 2.08mm2 |
| Shield Type | Tape |
| Shield Material | Bi-Laminate (Alum+Poly) |
| Shield Coverage | 100% |
| Drainwire type | 20 AWG (7x28) TC |
| Jacket Material | PVC - Polyvinyl Chloride |
| Jacket Color | Black |
| Insulation thickness (nom.) | 0.033 in (0.84 mm) |
| Insulation diameter (nom.) | 0.141 in (3.58 mm) |
| Jacket thickness (nom.) | 0.042 in (1.1 mm) |
| Overall cable diameter (nominal) | 0.402 in (10.2 mm) |
| Bulk cable weight | 97 lbs/1000ft |
| Nom. conductor DCR | 2.76 Ohm/1000ft |
| Nom. outer shield DCR | 7.37 Ohm/1000ft (24.2 Ohm/km) |
| Operating | -20°C to +60°C |
| Bend radius (stationary min.) | 4.0 in (100 mm) |
| Bend radius (installation min.) | 4.0 in (100 mm) |
| Max Pull Tension | 172.5 lbs (78.24 kg) |
| NEC / UL compliance | SJT |
| AWM compliance | SJT |
| European directive compliance | EU CE Mark, EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE) |
| APAC compliance | China RoHS II (GB/T 26572-2011) |
| Priced Per | FT |
Images are for reference only. Specifications may change without notice — verify suitability for your application before purchase. The manufacturer's documentation controls.
