Belden 19402 010, Portable Cordage SVT 3C 18 AWG PVC, Black Jacket
SKU:Belden 19402 010
● In stock
Description
Belden 19402 010 is UL Type SVT portable cordage for supplying power to appliances and tools. It features 3 stranded 18 AWG BC - Bare Copper conductors with PVC - Polyvinyl Chloride insulation and a black PVC - Polyvinyl Chloride outer jacket. The cord is unshielded and includes a paper tape separator for flexible handling. It is rated 60°C with an operating temperature range of -20°C to +60°C, and supports 7 Amps per Conductor @ 30°C.
Belden 19402 010 Applications
- Use it as portable cordage to supply power to appliances and tools.
Belden™ and all associated trademarks are the property of their respective owners.
Specifications
| Attribute | Value |
|---|---|
| Product type | Cordage |
| Number of Conductors | 3 |
| Conductor size | 18 AWG |
| Conductor stranding | 42x34 |
| Conductor Material | BC - Bare Copper |
| Conductor notes | 0.824mm2 |
| Insulation Material | PVC - Polyvinyl Chloride |
| Insulation thickness (nom.) | 0.018 in (0.46 mm) |
| Insulation diameter (nom.) | 0.084 in (2.1 mm) |
| Color Code | Light Blue, Brown, Green/Yellow |
| Outer jacket material | PVC - Polyvinyl Chloride |
| Separator | Paper Tape |
| Jacket thickness (nom.) | 0.034 in (0.86 mm) |
| Overall cable diameter (nominal) | 0.253 in (6.43 mm) |
| Jacket Color | Black |
| Shielding | Unshielded |
| Nom. conductor DCR | 6.66 Ohm/1000ft |
| Max. current | 7 Amps per Conductor @ 30°C |
| UL Voltage Rating | (Type SVT) |
| UL temperature | 60°C |
| Operating temperature | -20°C to +60°C |
| Bend radius (stationary min.) | 2.5 in (64 mm) |
| Bend radius (installation min.) | 2.5 in (64 mm) |
| Max Pull Tension | 61.5 lbs (27.9 kg) |
| Bulk cable weight | 39 lbs/1000ft |
| NEC / UL compliance | SVT |
| AWM compliance | SVT |
| Standards | UL/CSA |
| European directive compliance | EU CE Mark, EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE) |
| APAC compliance | China RoHS II (GB/T 26572-2011) |
| Priced Per | FT |
