Belden 19403 010, Portable Cordage Type SVT 3C 18 AWG PVC, Black Jacket
SKU:Belden 19403 010
● In stock
Description
Belden 19403 010 is a portable cordage, UL Type SVT, built with 3 conductor 18 AWG stranded bare copper conductors and a black PVC outer jacket with PVC insulation. It features shielding with Tri-Laminate (Alum+Poly+Alum) tape (100% coverage) plus a tinned copper (TC) braid (88%) and includes a 22 AWG (7x30) TC drainwire. Designed for indoor use, it carries a UL voltage rating of 300 V and a UL temperature rating of 60°C with an operating range of -20°C To +60°C.
Belden 19403 010 Key Features
- Portable cordage with UL Type SVT construction for flexible cord applications.
- 3 conductor 18 AWG stranded bare copper conductors (Conductor Stranding: 42x34).
- PVC insulation with a black PVC outer jacket.
- Shielded design using Tri-Laminate (Alum+Poly+Alum) tape (100% coverage) plus a tinned copper (TC) braid (88%).
- Includes a 22 AWG (7x30) TC drainwire for grounding and noise control.
- Rated UL voltage rating: 300 V and UL temperature: 60°C (Operating: -20°C To +60°C).
- Compliance markings include NEC / UL compliance: Article 400, SVT; AWM compliance: SVT; CEC / C(UL) compliance: LL7874.
Belden 19403 010 Applications
- Supports indoor cordage installations that require UL Type SVT construction.
- Reduces electrical noise in environments that benefit from a shielded cord design.
- Works well in setups that need a drainwire for grounding and noise control.
Belden™ and all associated trademarks are the property of their respective owners.
Specifications
| Attribute | Value |
|---|---|
| Product type | Cordage |
| Color Code | Blue, Brown, Green/Yellow |
| Nom. thickness (insulation) | 0.018 in (0.46 mm) |
| Nom. insulation diameter | 0.84 in (21 mm) |
| Nom. thickness (outer jacket) | 0.038 in (0.97 mm) |
| Nom. diameter (outer jacket) | 0.307 in |
| Overall cable diameter (nominal) | 0.307 in |
| Bulk cable weight | 65 lbs/1000ft |
| Nom. conductor DCR | 6.97 Ohm/1000ft |
| Max. current | 10 Amps per Conductor at 25ºC (7 Amps over 50 ft) |
| Nom. outer shield DCR | 2.69 Ohm/1000ft (8.83 Ohm/km) |
| Bend radius (stationary min.) | 3.07 in (78.0 mm) |
| Bend radius (installation min.) | 3.07 in |
| Max Pull Tension | 114 lbs (51.7 kg) |
| Environmental suitability | Indoor |
| European directive compliance | EU CE Mark, EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE) |
| APAC compliance | China RoHS II (GB/T 26572-2011) |
| Priced Per | FT |
Images are for reference only. Specifications may change without notice — verify suitability for your application before purchase. The manufacturer's documentation controls.
