Belden 19503 B59, Type STOWA 3C 18 AWG PVC Portable Cord
SKU:Belden 19503 B59
● In stock
Description
Belden 19503 B59 is a Type STOW portable cordage with 3 conductors of 18 AWG (42x34) BC - Bare Copper, PVC insulation, and a smooth PVC outer jacket with a paper tape separator. It is rated 600 V and UL temperature 60°C, with a max. current of 10 Amps per Conductor at 25ºC (7 Amps over 50 ft). This unshielded STOW Belflex matte black premium PVC cord is designed to operate from -35°C To +105 °C and uses an international color code: light blue, brown, green/yellow.
Belden 19503 B59 Applications
- Use it for demanding outdoor installations where a Type STOW portable cord is required.
- Choose it for environments where oil resistance is needed.
Belden™ and all associated trademarks are the property of their respective owners.
Specifications
| Attribute | Value |
|---|---|
| Product type | Cordage |
| Number of Conductors | 3 |
| Conductor size | 18 AWG |
| Stranding | 42x34 |
| Conductor Material | BC - Bare Copper |
| Insulation Material | PVC - Polyvinyl Chloride |
| Separator | Paper Tape |
| Jacket Material | PVC - Polyvinyl Chloride |
| Shielding | Unshielded |
| Color Code | Blue, Brown, Green/Yellow |
| Nom. thickness (insulation) | 0.032 in (0.81 mm) |
| Nom. insulation diameter | 0.110 in (2.79 mm) |
| Nom. thickness (outer jacket) | 0.07 in (1.8 mm) |
| Nom. diameter (outer jacket) | 0.38 in |
| Bulk cable weight | 68 lbs/1000ft |
| Nom. conductor DCR | 6.97 Ohm/1000ft |
| Max. current | 10 Amps per Conductor at 25ºC (7 Amps over 50 ft) |
| UL Voltage Rating | 600 V |
| UL temperature | 60°C |
| Operating | -35°C To +105 °C |
| Max Pull Tension | 63.9 lbs (29.0 kg) |
| Environmental suitability | Outdoor, Oil Resistance |
| Flammability / reaction to fire | VW-1 |
| NEC / UL compliance | Article 400, STOW |
| AWM compliance | STOW |
| Standards | UL/CSA |
| European directive compliance | EU CE Mark, EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE) |
| APAC compliance | China RoHS II (GB/T 26572-2011) |
| Priced Per | FT |
Images are for reference only. Specifications may change without notice — verify suitability for your application before purchase. The manufacturer's documentation controls.
