Belden 2413 004U, UTP Cat 6 CMP 23 4P FEP FRLSPVC Yellow
Description
Belden 2413 004U is a Category 6+ Enhanced Premise Horizontal Cable (350MHz) for high-performance Ethernet networks in plenum indoor spaces. This U/UTP 4-pair cable uses 23 AWG Solid Bare Copper conductors with PO+FEP insulation and a Flamarrest® PVC-LS jacket for Plenum-CMP installations. It supports Ethernet 1000BASE-T, Ethernet 100BASE-TX, and Ethernet 10BASE-T, and it is suitable for PoE, PoE+, and PoE++. The cable has a nominal overall diameter of 0.224 in (5.69 mm) and a Yellow jacket for identification in structured cabling systems.
Belden 2413 004U Key Features
- This is a Category 6+ Enhanced Premise Horizontal Cable (350MHz) for high-performance Ethernet networks.
- It is a plenum indoor cable with a Plenum-CMP fire rating.
- The cable features a U/UTP 4-pair construction with 23 AWG Solid Bare Copper conductors.
- It uses PO+FEP insulation and a Flamarrest® PVC-LS jacket.
- The nominal overall diameter is 0.224 in (5.69 mm), and it has a Yellow jacket.
Belden 2413 004U Applications
- It is designed for premise horizontal cabling runs in structured cabling systems.
- Ethernet 1000BASE-T network links are supported where consistent data transmission is required.
- Ethernet 100BASE-TX connections are supported in compatible network installations.
- Ethernet 10BASE-T connectivity is supported in compatible environments.
- Deployments using PoE, PoE+, and PoE++ are supported to deliver power over the network cabling.
Belden™ and all associated trademarks are the property of their respective owners.
Specifications
| Attribute | Value |
|---|---|
| Data category | Category 6 |
| Separator | Dielectric Tape (Patented) |
| Ripcord | Yes |
| Color Code | White/Blue Stripe & Blue, White/Orange Stripe & Orange, White/Green Stripe & Green, White/Brown Stripe & Brown |
| Non-Plenum number | 2412 |
| Patent information | This product has one or more applicable patents. More information on patents can be found at https://www.belden.com/patents . |
| Max. Conductor DCR | 78 Ohm/km (24 Ohm/1000ft) |
| Max. capacitance unbalance | 330 pF/100m |
| Delay (100 MHz) max. | 537.6 ns/100m |
| Delay skew (100 MHz) max. | 35 ns/100m |
| Nom. velocity of prop. | 72% |
| UL Voltage Rating | 300 V (CMP), 300 V (CL3P) |
| UL temperature | 90°C |
| Operating temperature | -20°C To +75°C |
| Installation temperature | 0°C To +50°C |
| Storage temperature | -20°C To +75°C |
| Bend radius (stationary min.) | 1.0 in (25 mm) |
| Bend radius (installation min.) | 2.25 in (57.2 mm) |
| Max Pull Tension | 25 lbs (11 kg) |
| Bulk cable weight | 26 lbs/1000ft |
| Environmental suitability | Plenum, Indoor |
| Flammability / reaction to fire | NFPA 262, UL 910 (Plenum), FT6, IEC 60332-1-2 |
| NEC / UL compliance | Article 800, CMP, CMP-LP (0.5A), CL3P-LP (0.5A) |
| CEC / C(UL) compliance | CMP |
| ICEA compliance | S-116-732 |
| NEMA Compliance | ANSI/NEMA WC-66 |
| IEEE compliance | IEEE 802.3bt Type 1, Type 2, Type 3, Type 4 |
| TIA/EIA compliance | ANSI/TIA-568.2-D Category 6 |
| ISO/IEC compliance | ISO/IEC 11801-1, IEC 61156-5 |
| Third party performance verification | Category 6 |
| CPR compliance | CPR Euroclass: Eca; CPR UKCA Class: Eca |
| European directive compliance | EU CE Mark, EU Directive 2015/863/EU (RoHS 2 amendment), REACH, EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE), REACH: 2020-01-16 |
| UK regulation compliance | UKCA Mark |
| APAC compliance | China RoHS II (GB/T 26572-2011) |
| Sustainability | Product Lens™, Environmental Product Declaration (EPD) Available |
| Priced Per | FT |
Images are for reference only. Specifications may change without notice — verify suitability for your application before purchase. The manufacturer's documentation controls.
