Belden 2413 005U, UTP Cat 6 CMP 23 4P Solid BC FRPO FEP FRLSPVC, Green Jacket
Description
Belden 2413 005U is a Category 6+ enhanced premise horizontal cable (350MHz) for indoor plenum installations. This U/UTP, 4 pair data cable is built with 23 AWG solid bare copper conductors and a green Flamarrest® PVC-LS jacket. It supports Ethernet 1000BASE-T, Ethernet 100BASE-TX, and Ethernet 10BASE-T, and is suitable for PoE, PoE+, and PoE++ deployments. NEC/UL listings include CMP-LP (0.5A) and CL3P-LP (0.5A).
Belden 2413 005U Key Features
- Category 6+ enhanced premise horizontal cable (350MHz) for structured cabling runs.
- U/UTP construction with 4 pairs for data networking installations.
- 23 AWG solid bare copper conductors for consistent conductor geometry.
- Green Flamarrest® PVC-LS jacket for plenum, indoor environments.
- Supports Ethernet 1000BASE-T, Ethernet 100BASE-TX, and Ethernet 10BASE-T.
- Suitable for PoE, PoE+, and PoE++ deployments.
- NEC/UL compliance includes Article 800, CMP, CMP-LP (0.5A), CL3P-LP (0.5A).
Belden 2413 005U Applications
- Use it for premise horizontal cable runs where consistent network cabling performance is required.
- Support Ethernet 1000BASE-T links in structured cabling installations.
- Deploy it with Ethernet 100BASE-TX networks for common LAN connectivity needs.
- Maintain compatibility with Ethernet 10BASE-T systems where legacy Ethernet connectivity is still in service.
- Enable PoE++, PoE+, and PoE deployments to deliver power and data over the same cabling infrastructure.
Belden™ and all associated trademarks are the property of their respective owners.
Specifications
| Attribute | Value |
|---|---|
| Data category | Category 6 |
| Type | Data |
| Insulation Material | PO+FEP - Polyolefin + Fluorinated Ethylene Propylene |
| Color Code | White/Blue Stripe & Blue, White/Orange Stripe & Orange, White/Green Stripe & Green, White/Brown Stripe & Brown |
| Separator | Dielectric Tape (Patented) |
| Ripcord | Yes |
| Non-Plenum number | 2412 |
| Overall cable diameter (nominal) | 0.224 in (5.69 mm) |
| Max Pull Tension | 25 lbs (11 kg) |
| Bulk cable weight | 26 lbs/1000ft |
| Bend radius (stationary min.) | 1.0 in (25 mm) |
| Bend radius (installation min.) | 2.25 in (57.2 mm) |
| Max. Conductor DCR | 78 Ohm/km (24 Ohm/1000ft) |
| Max. capacitance unbalance | 330 pF/100m |
| Delay (100 MHz) | 537.6 ns/100m |
| Delay skew (100 MHz) | 35 ns/100m |
| Nom. velocity of prop. | 72% |
| UL Voltage Rating | 300 V (CMP), 300 V (CL3P) |
| UL temperature | 90°C |
| Operating | -20°C To +75°C |
| Installation | 0°C To +50°C |
| Storage | -20°C To +75°C |
| Flammability / reaction to fire | NFPA 262, UL 910 (Plenum), FT6, IEC 60332-1-2 |
| CEC / C(UL) compliance | CMP |
| CPR compliance | CPR Euroclass: Eca; CPR UKCA Class: Eca |
| TIA/EIA compliance | ANSI/TIA-568.2-D Category 6 |
| ISO/IEC compliance | ISO/IEC 11801-1, IEC 61156-5 |
| IEEE compliance | IEEE 802.3bt Type 1, Type 2, Type 3, Type 4 |
| ICEA compliance | S-116-732 |
| NEMA Compliance | ANSI/NEMA WC-66 |
| Third party performance verification | Category 6 |
| European directive compliance | EU CE Mark, EU Directive 2015/863/EU (RoHS 2 amendment), REACH, EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE), REACH: 2020-01-16 |
| UK regulation compliance | UKCA Mark |
| APAC compliance | China RoHS II (GB/T 26572-2011) |
| Sustainability | Product Lens™, Environmental Product Declaration (EPD) Available |
| Patent information | This product has one or more applicable patents. More information on patents can be found at https://www.belden.com/patents. |
| Priced Per | FT |
Images are for reference only. Specifications may change without notice — verify suitability for your application before purchase. The manufacturer's documentation controls.
