Belden 2413 008U, Enhanced Category 6 Cable 4 pair UTP CMP Gray
Description
Belden 2413 008U is a Category 6+ Enhanced (350MHz) premise horizontal cable built with 4 pair of 23 AWG solid bare copper conductors in a U/UTP construction. It is designed for Ethernet 1000BASE-T, Ethernet 100BASE-TX, and Ethernet 10BASE-T, and supports PoE++, PoE+, and PoE. This Plenum-CMP cable features a Flamarrest® PVC-LS jacket in gray with a patented dielectric tape separator and a ripcord for easier pulls. It is suited for plenum and indoor installations where compliance and fire performance are required.
Belden 2413 008U Key Features
- Category 6+ Enhanced (350MHz) data category for premise horizontal cable installations.
- 4 pair construction with 23 AWG solid BC - bare copper conductors.
- U/UTP shielding type.
- Plenum-CMP jacket type with Flamarrest® PVC-LS jacket in gray.
- Includes a patented dielectric tape separator and ripcord for easier pulls.
- Supports Ethernet 1000BASE-T, Ethernet 100BASE-TX, Ethernet 10BASE-T, PoE++, PoE+, and PoE.
- Environmental suitability: plenum, indoor.
Belden 2413 008U Applications
- Use it for premise horizontal cable runs in building cabling systems.
- Support Ethernet 1000BASE-T links in high-performance network installations.
- Deploy it with Ethernet 100BASE-TX connections where Fast Ethernet is required.
- Maintain Ethernet 10BASE-T connectivity in legacy network environments.
- Deliver PoE++, PoE+, and PoE to compatible powered devices over the network.
Belden™ and all associated trademarks are the property of their respective owners.
Specifications
| Attribute | Value |
|---|---|
| Overall cable diameter (nominal) | 0.224 in (5.69 mm) |
| Insulation Material | PO+FEP - Polyolefin + Fluorinated Ethylene Propylene |
| Color Code | White/Blue Stripe & Blue, White/Orange Stripe & Orange, White/Green Stripe & Green, White/Brown Stripe & Brown |
| Jacket Material | PVC - Polyvinyl Chloride |
| Bulk cable weight | 26 lbs/1000ft |
| Non-Plenum number | 2412 |
| Max. Conductor DCR | 78 Ohm/km (24 Ohm/1000ft) |
| Max. capacitance unbalance | 330 pF/100m |
| Delay (100 MHz) | 537.6 ns/100m |
| Delay skew (100 MHz) | 35 ns/100m |
| Nom. velocity of prop. | 72% |
| UL Voltage Rating | 300 V (CMP), 300 V (CL3P) |
| UL temperature | 90°C |
| Operating | -20°C To +75°C |
| Installation | 0°C To +50°C |
| Storage | -20°C To +75°C |
| Min Bend Radius (Stationary) | 1.0 in (25 mm) |
| Min Bend Radius (Installation) | 2.25 in (57.2 mm) |
| Max Pull Tension | 25 lbs (11 kg) |
| Flammability / reaction to fire | NFPA 262, UL 910 (Plenum), FT6, IEC 60332-1-2 |
| CPR compliance | CPR Euroclass: Eca; CPR UKCA Class: Eca |
| NEC / UL compliance | Article 800, CMP, CMP-LP (0.5A), CL3P-LP (0.5A) |
| CEC / C(UL) compliance | CMP |
| ICEA compliance | S-116-732 |
| IEEE compliance | IEEE 802.3bt Type 1, Type 2, Type 3, Type 4 |
| NEMA Compliance | ANSI/NEMA WC-66 |
| TIA/EIA compliance | ANSI/TIA-568.2-D Category 6 |
| Third party performance verification | Category 6 |
| ISO/IEC compliance | ISO/IEC 11801-1, IEC 61156-5 |
| European directive compliance | EU CE Mark, EU Directive 2015/863/EU (RoHS 2 amendment), REACH, EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE), REACH: 2020-01-16 |
| UK regulation compliance | UKCA Mark |
| APAC compliance | China RoHS II (GB/T 26572-2011) |
| Sustainability | Product Lens™, Environmental Product Declaration (EPD) Available |
| Patent information | This product has one or more applicable patents. More information on patents can be found at https://www.belden.com/patents . |
| Priced Per | FT |
Images are for reference only. Specifications may change without notice — verify suitability for your application before purchase. The manufacturer's documentation controls.
