Belden 2413 009U, Enhanced Category 6 Cable 4 pair UTP CMP White
Description
Belden 2413 009U is a Category 6+ Enhanced premise horizontal cable (350MHz) designed for Ethernet networks and PoE delivery. It features a 4 pair construction with 23 AWG solid BC - bare copper conductors in a U/UTP design and a Plenum-CMP Flamarrest® PVC-LS jacket. The white jacket includes a patented dielectric tape separator and a ripcord to support easier pulls and prep. It is intended for plenum, indoor pathways and includes a UL voltage rating of 300 V (CMP), 300 V (CL3P).
Belden 2413 009U Key Features
- Category 6+ Enhanced premise horizontal cable (350MHz) for structured Ethernet cabling.
- 4 pair construction with 23 AWG solid BC - bare copper conductors in a U/UTP design.
- Plenum-CMP Flamarrest® PVC-LS jacket in white for plenum, indoor pathways.
- Patented dielectric tape separator and ripcord to help with cable pulls and preparation.
- UL voltage rating of 300 V (CMP), 300 V (CL3P).
Belden 2413 009U Applications
- Specified as a premise horizontal cable for structured cabling runs within a building.
- Supports Ethernet 1000BASE-T connectivity where Category 6 performance is required.
- Suitable for Ethernet 100BASE-TX network links in premise environments.
- Works for Ethernet 10BASE-T connections where this interface is deployed.
- Intended for PoE++, PoE+, and PoE delivery to power compatible network devices over the same cabling.
Additional Information
- This product has one or more applicable patents. More information on patents can be found at https://www.belden.com/patents.
Belden™ and all associated trademarks are the property of their respective owners.
Specifications
| Attribute | Value |
|---|---|
| Data category | Category 6 |
| Type | Data |
| Insulation Material | PO+FEP - Polyolefin + Fluorinated Ethylene Propylene |
| Pair color code | White/Blue Stripe & Blue, White/Orange Stripe & Orange, White/Green Stripe & Green, White/Brown Stripe & Brown |
| Jacket Material | PVC - Polyvinyl Chloride |
| Jacket trade name | Flamarrest® |
| Overall cable diameter (nominal) | 0.224 in (5.69 mm) |
| Bulk cable weight | 26 lbs/1000ft |
| Max. Conductor DCR | 78 Ohm/km (24 Ohm/1000ft) |
| Max. capacitance unbalance | 330 pF/100m |
| Delay (100 MHz) max. | 537.6 ns/100m |
| Delay skew (100 MHz) max. | 35 ns/100m |
| Nom. velocity of prop. | 72% |
| UL temperature | 90°C |
| Operating temperature | -20°C To +75°C |
| Installation temperature | 0°C To +50°C |
| Storage temperature | -20°C To +75°C |
| Bend radius (stationary min.) | 1.0 in (25 mm) |
| Bend radius (installation min.) | 2.25 in (57.2 mm) |
| Max Pull Tension | 25 lbs (11 kg) |
| Flammability / reaction to fire | NFPA 262, UL 910 (Plenum), FT6, IEC 60332-1-2 |
| NEC / UL compliance | Article 800, CMP, CMP-LP (0.5A), CL3P-LP (0.5A) |
| CEC / C(UL) compliance | CMP |
| CPR compliance | CPR Euroclass: Eca; CPR UKCA Class: Eca |
| TIA/EIA compliance | ANSI/TIA-568.2-D Category 6 |
| ISO/IEC compliance | ISO/IEC 11801-1, IEC 61156-5 |
| IEEE compliance | IEEE 802.3bt Type 1, Type 2, Type 3, Type 4 |
| ICEA compliance | S-116-732 |
| NEMA Compliance | ANSI/NEMA WC-66 |
| Third party performance verification | Category 6 |
| European directive compliance | EU CE Mark, EU Directive 2015/863/EU (RoHS 2 amendment), REACH, EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE), REACH: 2020-01-16 |
| UK regulation compliance | UKCA Mark |
| APAC compliance | China RoHS II (GB/T 26572-2011) |
| Sustainability | Product Lens™, Environmental Product Declaration (EPD) Available |
| Non-Plenum number | 2412 |
| Priced Per | FT |
